Product Name: Network Interface Module
Brand Name: GE
Model Number:IC200PBI001
Country of Origin:USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
General Electric |
Model Number: |
IC200PBI001 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
Delivery time in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
The IC200PBI001 is a PROFIBUS-DP Network Interface Unit (NIU) from the GE Fanuc VersaMax series. Operating as a PROFIBUS slave, the IC200PBI001 functions as an intelligent controller for up to 64 VersaMax I/O modules, bridging local I/O systems with a PROFIBUS master such as a PLC. The IC200PBI001 supports auto-detected data rates from 9.6 Kbaud to 12 Mbaud and handles up to 375 bytes of I/O data. With comprehensive diagnostics and flexible configuration, the IC200PBI001 ensures reliable data exchange in demanding industrial automation environments
Remote I/O Expansion: Enables VersaMax systems to extend I/O points to distant locations for distributed control systems
PROFIBUS Network Integration: Seamlessly integrates VersaMax I/O stations as PROFIBUS-DP slave nodes into existing PROFIBUS-based automation networks
Industrial Process Control: Ideal for manufacturing plants, automated production lines, chemical, and oil & gas facilities requiring high-speed, reliable data exchange between PLCs and field devices
Data Acquisition & Monitoring: Collects and transmits data from PROFIBUS network devices to VersaMax PLCs for centralized monitoring and control
High-Density Analog/Digital Setups: Manages up to 64 mixed I/O modules per station, suitable for high-density analog and digital signal processing
PROFIBUS-DP Slave Operation: Functions as a slave on a PROFIBUS-DP network, automatically exchanging I/O, status, control, and diagnostic data with a master device
Wide Data Rate Support: Auto-detects network speeds from 9.6 Kbaud to 12 Mbaud, ensuring compatibility with diverse master devices
Flexible Network Addressing: Rotary switch allows manual selection of PROFIBUS addresses from 1 to 125
Comprehensive I/O Capacity: Supports up to 64 I/O modules across 8 racks, with a maximum of 375 bytes of I/O data
Output Default/Hold Last State: Configurable output behavior — outputs can either revert to a default state or maintain the last state when communication with the master is lost
Five LED Indicators: Real-time visual status for power, health, fault, network, and force conditions
Automatic Autoconfiguration: I/O station modules are automatically configured upon power-up, simplifying setup and reducing commissioning time
Compatibility with High-Density Analog Modules: Fully compatible with all VersaMax High-Density Analog Modules
AS-i Master Compatibility: Compatible with the AS-i Network Master module for expanded fieldbus integration
Firmware Upgradable: Firmware can be easily updated using IC200CBL002 cable and PC software
Acts as a controller for a set of VersaMax I/O modules, enabling a full I/O station to communicate over a PROFIBUS-DP network
Bridges local I/O systems (discrete and analog) with a PROFIBUS master device such as a PLC, DCS, or HMI
Provides real-time diagnostic feedback via onboard LEDs and extended diagnostic data reported to the master
Manages output behavior during communication loss, either defaulting to a preset state or holding the last known state
Supports autoconfiguration of I/O modules in the station upon power-up, eliminating manual configuration and streamlining system integration
Q1: What is the IC200PBI001 ?
A1: The IC200PBI001 is a PROFIBUS-DP Network Interface Unit (NIU) from the VersaMax series, operating as a PROFIBUS slave that controls up to 64 I/O modules.
Q2: How many I/O modules can the IC200PBI001 support?
A2: It supports up to 64 I/O modules per NIU, distributed across up to 8 racks with a maximum of 8 modules per rack.
Q3: What data rates are supported by the IC200PBI001 ?
A3: It supports auto-detected data rates from 9.6 Kbaud to 12 Mbaud, including all intermediate speeds (19.2, 93.75, 187.5, 500, 1500 Kb/s, 3 Mb/s, 6 Mb/s).
Q4: How does the IC200PBI001 handle outputs when communication is lost?
A4: It features configurable output behavior — outputs can be set to either revert to a default state or hold the last known state upon communication loss with the master.
Q5: Can the IC200PBI001 be used with all VersaMax analog modules?
A5: Yes, this version of the IC200PBI001 is fully compatible with all VersaMax High-Density Analog Modules.
