Product Name:redundant digital output IOTA
Brand Name:Honeywell
Model Number:8C-TDODB1 51307151-175
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Honeywell |
Model Number: |
8C-TDODB1 51307151-175 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Description |
|
Product Model |
8C-TDODB1 / 51307151-175 |
|
System Type |
Honeywell Series 8 I/O |
|
Output Channels |
32-point digital output |
|
Output Type |
24VDC current sinking |
|
IOTA Type |
Redundant Digital Output IOTA |
|
Channel Protection |
Electronic short-circuit protection |
|
Field Wiring |
Modular connector system |
|
Operating Voltage |
24 VDC |
|
Power Consumption |
Low-power system design |
|
Isolation |
System-to-field via IOTA design |
|
Operating Temperature |
0°C to 60°C |
|
Storage Temperature |
-40°C to 85°C |
|
Dimensions |
29.4x12x6.3cm |
|
Weight |
0.42kg |
The 8C-TDODB1 51307151-175 is a high-reliability 32-channel digital output solution designed for industrial control systems requiring stable switching performance and robust field integration. It is part of Honeywell’s Series 8 I/O architecture and supports demanding automation environments with compact design and enhanced thermal management.
The 8C-TDODB1 51307151-175 delivers current-sinking 24VDC outputs with full electronic short-circuit protection. Its redundant I/O architecture improves system availability, while integrated diagnostics ensure continuous signal integrity and fault detection. The module is engineered for high-density installations with simplified wiring through modular field connectors.
Designed for scalable process automation, the 8C-TDODB1 51307151-175 integrates seamlessly with Series 8 controllers, offering efficient installation, reduced maintenance cost, and dependable operation in harsh industrial environments.
Q1: What type of outputs does 8C-TDODB1 support?
A1: It supports 32-channel 24VDC sinking digital outputs.
Q2: Does the module support redundancy?
A2: Yes, it is designed with a redundant IOTA configuration for higher reliability.
Q3: Is the module protected against short circuits?
A3: Yes, each output channel has electronic short-circuit protection.
Q4: What industries commonly use this module?
A4: It is used in power plants, substations, chemical plants, steel mills, and manufacturing systems.
Q5: How is field wiring handled?
A5: It uses modular connectors that simplify installation and maintenance.
| Number | Describe |
|---|---|
| 8C-TAIMA1 / 8U-TAIMA1 | TC/RTD IOTA module, coated or uncoated version, designed for thermocouple and RTD signal acquisition, 16-channel support, 9-inch IOTA platform for Series 8 system integration |
| 8C-TAIXA1 / 8U-TAIXA1 | Analog input single-ended IOTA module, 16-channel, 6-inch size, supports standard analog signal processing for Series 8 control systems |
| 8C-TAIDA1 / 8U-TAIDA1 | Analog input differential IOTA module, 16-channel, 9-inch configuration, optimized for stable multi-signal acquisition in industrial environments |
| 8C-TAIXB1 / 8U-TAIXB1 | Redundant single-ended analog input IOTA module, 16-channel, 12-inch design, enhanced reliability for critical process control applications |
| 8C-TAIDB1 / 8U-TAIDB1 | Redundant differential analog input IOTA module, 16-channel, 12-inch structure, designed for high-availability industrial automation systems |
| 8C-TAOXA1 / 8U-TAOXA1 | Analog output IOTA module, 16-channel, 6-inch format, supports precise 4–20mA output control for process regulation |
| 8C-TAOXB1 / 8U-TAOXB1 | Redundant analog output IOTA module, 16-channel, 12-inch configuration, built for high-reliability output control systems |
| 8C-TDILA1 / 8U-TDILA1 | Digital input 24VDC IOTA module, 32-channel, 9-inch design, coated or uncoated version for industrial signal acquisition |
| 8C-TDILB1 / 8U-TDILB1 | Redundant digital input 24VDC IOTA module, 32-channel, 12-inch structure, high-availability input solution for Series 8 systems |
| 8C-TDODA1 / 8U-TDODA1 | Digital output IOTA module, 32-channel, 9-inch format, standard 24VDC output control for industrial automation systems |
| 8C-TDODB1 / 8U-TDODB1 | Redundant digital output IOTA module, 32-channel, 12-inch design, high-reliability output module for critical control applications |
