Product Name:Digital Input Card
Brand Name:Honeywell
Model Number:51304690-100
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Honeywell |
Model Number: |
51304690-100 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Specification |
|
Product Model |
51304690-100 |
|
Type |
Industrial Communication Interface Board |
|
System Compatibility |
Honeywell TDC 3000X |
|
Network Type |
Local Control Network (LCN) |
|
Function |
Data communication & system interface |
|
Mounting Position |
Rear I/O chassis |
|
Compatible Modules |
Five / Ten Slot Modules |
|
Signal Type |
Digital industrial communication |
|
Power Supply |
Backplane powered |
|
Operating Temperature |
0°C to 60°C |
|
Storage Temperature |
-40°C to 85°C |
|
Humidity Range |
5%–95% non-condensing |
|
Dimension (approx.) |
2.9x31.8x27.8cm |
|
Weight (approx.) |
0.6kg |
The 51304690-100 is an industrial communication and control interface board designed for Honeywell TDC 3000X Five- and Ten-Slot Module systems. It provides reliable data exchange between system processors and I/O subsystems, ensuring stable operation of distributed control architectures in complex automation environments.
As part of the Honeywell LCN-compatible board family, the 51304690-100 supports seamless integration with related modules such as CLCN, CNI, and other network interface boards. It enables efficient routing of process data across control layers, improving system responsiveness and communication reliability within plant-wide automation networks.
Engineered for mission-critical industrial applications, the 51304690-100 delivers high noise immunity, stable node communication, and long-term operational durability. It is widely used in continuous process industries requiring dependable control network performance and scalable system connectivity.
Q1: What is the 51304690-100 used for?
A1: It is used as a communication interface board for TDC 3000X systems, enabling stable data exchange across control networks.
Q2: Is it compatible with LCN architecture?
A2: Yes, it is fully designed for integration with Honeywell Local Control Network (LCN) systems.
Q3: Where is this board installed?
A3: It is installed in the rear I/O section of Five- and Ten-Slot modules.
Q4: Can it be used in harsh environments?
A4: Yes, it is built for industrial conditions with high EMI, vibration, and temperature variation.
Q5: Does it support system expansion?
A5: Yes, it supports scalable network integration within modular control system architectures.
| Number | Description |
|---|---|
| MLO-RTCA | Option, RTC function with BAT |
| MLO-AD02A | Option, Current/Voltage Input (2 ch) |
| MLO-DA02A | Option, Current/Voltage Output (2 ch) |
| MLO-AH02A | Option, Current/Voltage Input 1ch, Current/Voltage Output 1ch |
| MLO-TC02A | Option, TC Input (2 ch) |
| MLO-RD01A | Option, RTD Input (1 ch) |
| MLO-DC04A | Option, DC24V Input (4 ch) |
| MLO-TN04A | Option, Open Collector Output (4 ch) |
| MLO-M2MB | Option, Memory, 2MB |
| PMC-310S | Loader Cable (Serial) |
| USB-301A | Loader Cable (USB) (Note 3) |
| TG7-1H40S | Smart Link Terminal Board 40P |
| R40H/20HH-05S-XBM3 | Smart Link Cable Ass'y 20x2-40P, 0.5 Meter (Note 4) |
| R40H/20HH-10S-XBM3 | Smart Link Cable Ass'y 20x2-40P, 1.0 Meter (Note 4) |
| C40HH-15SB-XBI | Smart Link Cable Ass'y 40-40P, 1.5 Meter (Note 5) |
| C40HH-30SB-XBI | Smart Link Cable Ass'y 40-40P, 3.0 Meter (Note 5) |
