Overview

Brand Name:	Honeywell
Model Number:	51304831-100
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Specification
Product Model	51304831-100
Type	TPDG I/O Interface Board
System	Honeywell TDC 3000X
Function	Display & Peripheral Interface
Mounting Location	Rear I/O chassis
Compatible Module	Five / Ten Slot Module
Communication	LCN / Peripheral signal routing
Power Supply	System backplane powered
Operating Temperature	0°C to 60°C
Storage Temperature	-40°C to 85°C
Humidity	5%–95% non-condensing
Dimension (approx.)	22.3x14x1.5cm
Weight (approx.)	0.18kg

Description

The 51304831-100 is a TPDG I/O interface board designed for Honeywell TDC 3000X systems, providing reliable signal routing and peripheral integration within Five- and Ten-Slot Module architectures. It supports stable communication between the Universal Station display subsystem and connected input/output devices, ensuring consistent system performance in industrial control environments.

As part of the TPDG family, the 51304831-100 works alongside related modules such as TPDG I/O configurations and other Honeywell display interface boards. It manages multiple peripheral connections including touchscreen, keyboard, mouse/trackball, printer, and SCSI-based storage interfaces, enabling flexible operator station functionality and seamless HMI interaction.

Engineered for industrial automation environments, the 51304831-100 ensures robust signal integrity, configurable display background pinning, and dependable interface control. It is widely used in process control systems requiring stable visualization, operator interaction, and long-term reliability in mission-critical applications.

Applications

Power plants: Used for generator monitoring, turbine control visualization, and operator station interface
Substations: Enables switchyard monitoring, protection system visualization, and signal acquisition
Chemical plants: Supports process control HMI and intrinsically safe operator interaction systems
Steel mills: Ensures stable control interface in high-temperature and EMI-heavy environments
Machinery manufacturing: Applied in automated production lines, robotics control panels, and HMI systems

Features

Supports TPDG display interface architecture
Multiple peripheral connectivity options (keyboard, mouse, printer, SCSI)
Configurable CRT background color pinning function
Industrial-grade signal stability and noise resistance
Compatible with Honeywell TDC 3000X Universal Station systems

Functions

Manages display and operator interface signal routing
Controls peripheral device communication in control systems
Provides selectable background color initialization for CRT systems
Supports touchscreen and input device integration
Ensures stable HMI data transmission across modules

FAQ

Q1: What is the 51304831-100 used for?
A1: It is used as a TPDG I/O interface board for managing display and peripheral connections in TDC 3000X systems.

Q2: Does it support touchscreen devices?
A2: Yes, it supports touchscreen signal and power interfaces within the system.

Q3: Where is this board installed?
A3: It is installed in the rear I/O section of Five- or Ten-Slot Modules.

Q4: What peripherals can it connect to?
A4: It supports keyboard, mouse/trackball, printer, SCSI drives, and CRT display interfaces.

Q5: Is it suitable for harsh industrial environments?
A5: Yes, it is designed for stable operation in high EMI and continuous industrial process conditions.

Spares

Number (I/O Module / Coated)	Description
51304159-100	AMR I/O Redundant AM Interface I/O
51304159-200	AMR I/O AM Redundancy I/O EC
51305072-200	CLCN-A LCN I/O Board (Dual Node LCN Coax A I/O Board) EC
51305072-500	CLCN-A LCN I/O Board (Dual Node LCN Coax A I/O Board), Replaces KLCN-CA
51305072-800	CLCN-A LCN I/O Board (Dual Node LCN Coax A I/O Board) EC
51305072-100	CLCN-A/B LCN I/O Board EC
51305072-400	CLCN-A/B LCN I/O Board
51305072-700	CLCN-A/B LCN I/O Board EC
51305072-300	CLCN-B LCN I/O Board (Dual Node LCN Coax B I/O Board) EC
51305072-600	CLCN-B LCN I/O Board (Dual Node LCN Coax B I/O Board), Replaces KLCN-CB
51305072-900	CLCN-B LCN I/O Board (Dual Node LCN Coax B I/O Board) EC
80360209-001	CLI I/O Communications Line Interface I/O (RS-232C)
80360230-001	CLI I/O Communications Line Interface I/O (RS-449)
51196701-100	CLI/A Communications Line Interface (RS-449) EC
51304537-100	CNI I/O Communications Network Interface
51304537-200	CNI I/O Communications Network Interface I/O Board EC
51109919-100	CS/R Clock Source/Repeater
51304286-100	CS/R Clock Source/Repeater (with Precision Clock also called PCS/R)
51304286-200	CS/R Clock Source/Repeater EC
51108088-100	DHI I/O Data Hiway Interface I/O
51108088-200	DHI I/O Data Hiway Interface I/O Board EC
51304270-100	EPDG I/O Enhanced Peripheral Display Generator I/O
51402447-100	EPDGC-1 Enhanced Peripheral Display Generator I/O Board-1 EC
51402447-200	EPDGC-2 Enhanced Peripheral Display Generator I/O Board-2 EC
51304584-300	EPDGP I/O Enhanced Peripheral Display Generator I/O (Replaces EPDG I/O)
51304812-100	EPLCI I/O Enhanced Programmable Logic Controller Interface I/O
51304812-200	EPLCI I/O Enhanced Programmable Logic Controller Interface I/O EC
