Product Name:Analog Output Module
Brand Name:Honeywell
Model Number:8C-PAOHA1 51454469-275
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Honeywell |
Model Number: |
8C-PAOHA1 51454469-275 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Details |
|
Product Model |
8C-PAOHA1 / 51454469-275 |
|
Type |
Analog Output with HART |
|
Output Signal |
4–20 mA DC |
|
Channels |
16 |
|
HART Support |
Yes |
|
IOTA Compatibility |
8C-TAOXA1 / 8C-TAOXB1 |
|
Redundancy |
Supported |
|
Resolution |
±0.05% Full Scale |
|
Accuracy |
±0.2% @ 25°C |
|
Load Resistance |
50–800 Ω |
|
Response Time |
≤80 ms |
|
Open Circuit Voltage |
Max 22 V |
|
Dimension |
6x15.6x14.3cm |
|
Weight |
0.3kg |
|
Operating Temp |
0°C to 60°C |
|
Protection |
Conformal coated industrial design |
The 8C-PAOHA1 51454469-275 Analog Output with HART module is engineered for precise 4–20 mA signal delivery in advanced industrial automation systems. It is part of the Series 8 I/O platform and works seamlessly with compatible modules such as 8C-PAOHA1, 8C-PAOH51, and IOTA bases including 8C-TAOXA1 and 8C-TAOXB1, ensuring stable process control performance.
This 16-channel output module integrates HART communication capability, enabling intelligent field device interaction and enhanced diagnostics. It supports both standard and redundant configurations, providing flexible deployment in mission-critical control environments.
Designed for harsh industrial conditions, the 8C-PAOHA1 51454469-275 delivers high accuracy, fast response time, and configurable fail-safe behavior. It is widely used in actuator control, valve positioning, and continuous process regulation systems.
Q1: What is the main function of 8C-PAOHA1?
A1: It provides 16-channel 4–20 mA analog output with HART communication for process control.
Q2: Does it support redundancy?
A2: Yes, redundancy is supported through compatible IOTA configurations.
Q3: What devices can it control?
A3: It is used for actuators, valves, and industrial control instruments.
Q4: What is the output accuracy?
A4: It delivers ±0.2% full-scale accuracy at 25°C.
Q5: Does it support fault detection?
A5: Yes, it includes open-wire detection and channel diagnostics.
| Number (I/O Module Coated) | Description |
|---|---|
| 8C-PAIH54 | High-level AI HART, Differential |
| 8C-TAIDA1 | AI IOTA |
| 8C-TAIDB1 | AI IOTA Redundant |
| 8C-PAIHA1 | High-level AI HART, Single-ended |
| 8C-PAINA1 | High-level AI w/o HART, Single-ended |
| 8C-TAIXA1 | AI IOTA |
| 8C-TAIXB1 | AI IOTA Redundant |
| 8C-PAIMA1 | Low-level AI – RTD & TC |
| 8C-TAIMA1 | AI IOTA |
| 8C-PAOHA1 | Analog Output HART |
| 8C-PAONA1 | Analog Output w/o HART |
| 8C-TAOXA1 | AO IOTA |
| 8C-TAOXB1 | AO IOTA Redundant |
| 8C-PDILA1 | Digital Input 24V |
| 8C-PDISA1 | Digital Input Sequence of Events |
| 8C-PDIPA1 | Digital Input 24V Pulse Accumulation |
| 8C-TDILA1 | DI 24V IOTA |
| 8C-TDILB1 | DI 24V IOTA Redundant |
| 8C-PDODA1 | DO 24V Bussed Out |
| 8C-TDODA1 | DO IOTA |
| 8C-TDODB1 | DO IOTA Redundant |
| 8C-SDOX01 | DO Relay Extension |
