Product Name:High Level Analog Input Module
Brand Name:Honeywell
Model Number:900A16-0101
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Honeywell |
Model Number: |
900A16-0101 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Details |
|
Model |
900A16-0101 |
|
Type |
High Level Analog Input Module |
|
Channels |
16 isolated inputs |
|
Input Types |
Voltage / mA configurable |
|
Isolation |
400 VDC point-to-point, 1 kV to logic |
|
Accuracy |
±0.1% full scale |
|
A/D Resolution |
15-bit |
|
Update Rate |
100 ms |
|
Power Supply |
5V: 75 mA max / 24V: 50 mA max |
|
Input Impedance |
>1 MΩ (V), 250 Ω (mA) |
|
Dimensions |
13.5x15.2x3.3cm |
|
Weight |
0.22kg |
The 900A16-0101 High Level Analog Input Module is designed for precise multi-channel signal acquisition within the Honeywell ControlEdge HC900 process control platform. It provides up to 16 configurable input points supporting voltage and current signals, enabling flexible integration across complex industrial automation systems. With advanced point-to-point and backplane galvanic isolation, the module ensures high signal integrity and stable performance in electrically noisy environments.
The 900A16-0101 performs synchronized A/D conversion aligned with controller execution, reducing latency and improving real-time process accuracy. Its parallel processing architecture allows system expansion without increasing scan time, making it highly scalable for large control applications.
Built-in diagnostics, field calibration capability, and per-channel failsafe configuration enhance operational reliability. The module is fully compatible with Honeywell ControlEdge HC900 Controller systems for demanding industrial environments requiring precision and uptime.
Q1: What signals does the 900A16-0101 support?
A1: It supports configurable voltage and current input signals per channel.
Q2: How many input channels are available?
A2: The module provides 16 isolated analog input channels.
Q3: Is the 900A16-0101 electrically isolated?
A3: Yes, it features point-to-point and logic isolation for high safety.
Q4: Can the module be calibrated in the field?
A4: Yes, each channel supports individual field calibration.
Q5: What system is it compatible with?
A5: It is designed for Honeywell ControlEdge HC900 controller systems.
| Number | Description |
|---|---|
| 900G02-0102 | Digital Input Module, DC Voltage, 16 Ch |
| 900G03-0202 | Digital Input Module, 120/240 VAC, 16 Ch |
| 900G32-0101 | Digital Input Module, 24VDC, 32 Ch |
| 900G01-0202 | Digital Input Module, Contact Type, 16 Ch |
| 900G04-0101 | Digital Input Module, AC/DC Voltage, 16 Ch |
| 900H03-0202 | Digital Output Module, 120/240 VAC, 8 Ch |
| 900H32-0102 | Digital Output Module, 24VDC, 32 Ch |
| 900H01-0202 | Relay Output Module, 8 Ch |
| 900K01-0201 | Pulse/Frequency I/O Module |
| 900P01-0301 | Power Supply 120/240VAC, 60W |
| 900P24-0301 | Power Supply 24VDC, 60W |
| 900P01-0401 | SIL Power Supply 120/240VAC, 60W |
| 900P24-0401 | SIL Power Supply 24VDC, 60W |
| 900PSM-0200 | Power Status Module, Redundant |
| 900S50-0460 | ControlEdge Scanner Module, Single Port |
| 900S75-0460 | ControlEdge Scanner Module, Dual Port |
