Honeywell CC-PAOH01 51405039-176 Analog Output Ready For Ship

Honeywell CC-PAOH01 51405039-176 Analog Output Ready For Ship

Product Name:Analog Output

Brand Name:Honeywell

Model Number:CC-PAOH01 51405039-176

Country of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

honeywell cc paoh01 51405039 176 analog output ready for ship-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Honeywell
CC-PAON01 51410070-175	CC-PAOH01 51405039-176
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Description
Product Model	CC-PAOH01 51405039-176
Brand	Honeywell
Product Type	Analog Output Module with HART
Output Signal	4–20 mA with HART
Output Channels	16 Channels
Output Ripple	<100 mV peak-to-peak
Output Linearity	±0.05% of Full Scale
Calibrated Accuracy	±0.35% of Full Scale
Output Temperature Drift	0.005% /°C
Maximum Resistive Load	800 Ohms
Maximum Output Voltage	16 V
Open Circuit Voltage	22 V
Response Time	≤80 ms to 1% final value
Redundancy Support	Optional
FAILOPT Modes	Hold Last / Safe Value
Open Wire Detection	Supported
Compatible IOTA	CC-TAOX01, CC-TAOX11, CC-GAOX11, CC-GAOX21
Dimensions	14.5x16.5x6cm
Weight	0.4kg

Description

The CC-PAOH01 51405039-176 is a high-performance Analog Output module with integrated HART communication, designed for Honeywell Experion Series C process automation systems. It provides stable 4–20 mA current signals for precise control of actuators, valves, and industrial instrumentation, ensuring reliable operation in continuous process environments.

The CC-PAOH01 supports advanced diagnostic capabilities, configurable FAILOPT safety behavior per channel, and optional redundancy for improved system availability. It is compatible with multiple IOTA assemblies such as CC-TAOX01, CC-TAOX11, CC-GAOX11, and CC-GAOX21, enabling flexible deployment across both standard and redundant control architectures.

With HART-enabled multivariable communication, open-wire detection, and high output accuracy, the Honeywell CC-PAOH01 51405039-176 enhances field device visibility, improves maintenance efficiency, and ensures robust performance in mission-critical industrial automation systems.

Applications

Power plants: Used for turbine actuator control, generator regulation, and monitoring systems.
Substations: Enables protection relays, switchgear control, and signal acquisition.
Chemical plants: Supports process automation and safe instrumentation monitoring.
Oil & gas facilities: Provides stable analog output for control valves and field instruments.
Steel mills: Ensures reliable control in high-temperature and high-EMI environments.
Water treatment plants: Used for pump control, dosing systems, and flow regulation.
Manufacturing plants: Supports automated production lines and robotic system control.

Features

16-channel 4–20 mA analog output
Integrated HART communication capability
Advanced self-diagnostic functions
Configurable FAILOPT per channel
Optional system redundancy support
Open-wire detection with fault alarm
High precision and stable signal output
Low ripple performance design
Industrial-grade reliability for continuous operation
Compatible with Honeywell Series C IOTA modules

Functions

Provides precise analog signal output to field devices
Enables HART-based device configuration and diagnostics
Supports actuator and valve control in process systems
Detects wiring faults and channel failures automatically
Maintains safe output state during system failure
Improves asset monitoring and predictive maintenance
Supports distributed control system integration
Ensures stable performance in critical industrial applications

FAQ

Q1:What is the main function of theCC-PAOH01 51405039-176?
A1:It delivers 4–20 mA analog output signals with HART communication for industrial process control.

Q2:How many output channels does the module support?
A2:It supports 16 independent analog output channels.

Q3:Does theCC-PAOH01support redundancy?
A3:Yes, it supports optional redundancy for higher system availability.

Q4:What IOTA modules are compatible with this model?
A4:It is compatible withCC-TAOX01,CC-TAOX11,CC-GAOX11, andCC-GAOX21.

Q5:Which industries commonly use this module?
A5:It is widely used in power plants, chemical plants, oil & gas, steel mills, and manufacturing automation systems.
