Honeywell FC-TSDO-0824 Safe digital output FTA (24 Vdc, 8 channels) Ready For Ship, China Honeywell FC-TSDO-0824 Safe digital output FTA (24 Vdc, 8 channels) Ready For Ship Manufacturers, Suppliers, Factory

Overview

Brand Name:	Honeywell
Model Number:	FC-TSDO-0824
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Description
Product Model	FC-TSDO-0824
Function	Safe digital output FTA interface
Output Channels	8 channels
System Interface	SICC-0001/Lx cable connection
Compatible Module	SDO-0824 (redundant pair supported)
Max Voltage	36 Vdc
Max Current	1.5 A per channel
Mounting Type	DIN EN TS32 / TS35 rail
Terminal Type	Screw terminals
Material	Industrial-grade insulated housing
Dimension	60 × 70 × 58 mm
Weight	0.25 kg
Operating Temperature	-5°C to +60°C

Description

The FC-TSDO-0824 is a compact field termination assembly designed to interface Safety Manager digital output systems with external field wiring through the SICC-0001/Lx system interconnection cable. It enables reliable connection of up to eight channels from SDO-0824 output modules, ensuring stable signal routing in safety-critical control environments.

The FC-TSDO-0824 is engineered for DIN-rail mounting and provides screw terminal connections for fast and secure field wiring installation. Its modular structure supports efficient cabinet integration while maintaining strong electrical continuity and mechanical stability.

As part of the Safety Manager FTA portfolio, including variants like TSDO-0824, it delivers robust signal distribution, supporting industrial automation systems that require dependable digital output interfacing in demanding process control applications.

Applications

Power plants: Used for generator set status monitoring and relay protection.
Substations: Enable bus differential control, line protection, and switchyard signal acquisition.
Chemical plants: Integrate process automation and intrinsically safe signal monitoring.
Steel mills: Support control logic in high temperature and high EMI environments.
Machinery manufacturing: Used in automated production lines, robotics, and packaging systems.

Features

8-channel safe digital output interface
DIN-rail snap-in installation design
Direct connection via SICC-0001/Lx cable
Compact modular field termination design
High electrical reliability and stability
Screw terminal wiring for secure connections
Compatible with Safety Manager output modules

Functions

Distributes digital output signals to field devices
Provides safe connection between controller and field wiring
Supports redundant output module configurations
Ensures stable signal transmission in automation systems
Simplifies cabinet wiring and maintenance
Enhances system reliability in safety applications

FAQ

Q1: What is FC-TSDO-0824 used for?
A1: It is used as a field termination interface for safe digital output connections in Safety Manager systems.

Q2: How many channels does FC-TSDO-0824 support?
A2: It supports 8 digital output channels.

Q3: Which cable is used with FC-TSDO-0824?
A3: It connects via the SICC-0001/Lx system interconnection cable.

Q4: Is FC-TSDO-0824 DIN rail mountable?
A4: Yes, it is designed for standard TS32 / TS35 DIN rail installation.

Q5: Can it work with redundant output modules?
A5: Yes, it supports redundant SDO-0824 module configurations.

Spares

number	describe
TSDI-1624	Safe digital input FTA (24 Vdc, 16 channels)
TSDI-1648	Safe digital input FTA (48 Vdc, 16 channels)
TSDI-16UNI	Safe digital input FTA (24/48 Vdc, NAMUR, 16 channels)
TSDI-1624C	Safe current-limited digital input FTA (24 Vdc, 16 channels)
TSDI-16115	Safe active/passive digital input FTA (115 Vac/dc, 16 channels)
TIDI-1624	Non-safe isolated passive digital input FTA (16 channels)
TSAI-0410	Safe analog input FTA (4 channels)
TSAI-1620m	Safe 0-20 mA and 4-20 mA analog input FTA (16 channels)
TSHART-1620m	Safe 0-20 mA and 4-20 mA analog input FTA with HART interface (16 channels)
TSGAS-1624	Safe gas/flame detector input FTA (0-20 mA, 16 channels)
TSGASH-1624	Safe gas/flame detector input FTA with HART interface (0-20 mA, 16 channels)
TSGASH-1624P	Safe gas/flame detector input FTA with HART interface (0-20 mA, 16 channels)
TSFIRE-1624	Safe fire detector input FTA with line monitoring (24 Vdc, 16 channels)
TSDO-0824	Safe digital output FTA (24 Vdc, 8 channels)
TSDO-0824C	Conformal coated safe digital output FTA, current limited (24 Vdc, 8 channels)
TDOL-0724	Line-monitored relay contact digital output (7 channels, 24 Vdc)
