Product Name:Safe 0-20 mA and 4-20 mA analog input FTA
Brand Name:Honeywell
Model Number:FC-TSHART-1620M
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Honeywell |
Model Number: |
FC-TSHART-1620M |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Description |
|
Product Model |
FC-TSHART-1620M |
|
Function |
Safe analog input FTA with HART interface |
|
Input Channels |
16 channels (2 groups of 8) |
|
Input Signal Range |
0–20 mA / 4–20 mA |
|
Output to SAI Module |
0–4 Vdc converted signal |
|
Input Resistance |
250 Ω ±1% |
|
Power Supply |
30 Vdc external |
|
Fuse Rating |
315 mAT slow-acting |
|
Isolation |
Channel-to-channel and system isolation |
|
Mounting Type |
DIN EN TS32 / TS35 rail |
|
Dimension |
25x7x5.8cm |
|
Weight |
0.36kg |
|
Operating Temperature |
-5°C to +60°C |
TheFC-TSHART-1620Mfield termination assembly is designed as the robust interface between field instrumentation and theSAI-1620mhigh-density analog input system within Safety Manager architectures. It converts and conditions 0(4)–20 mA signals into precise voltage levels while ensuring SIL3-compliant signal integrity for safety-critical applications. Together with related modules such asTSAI-1620mandBSAI-1620mE, it supports flexible signal conversion for process sensors including transmitters, thermocouples, and RTDs.
TheFC-TSHART-1620Malso integrates HART communication capability, enabling seamless asset diagnostics through external multiplexers. In addition, it provides isolated power distribution with monitored redundancy for field devices, ensuring stable loop operation even in demanding environments.
Built for DIN-rail installation, the module delivers reliable signal interfacing, electrical isolation, and industrial-grade protection for modern safety automation systems.
Q1: What is FC-TSHART-1620M used for?
A1: It is used as a safe analog input termination module with HART communication for industrial safety systems.
Q2: Does FC-TSHART-1620M support HART devices?
A2: Yes, it integrates a built-in HART interface for field device communication and diagnostics.
Q3: How many input channels does it support?
A3: It supports 16 analog input channels grouped into two isolated sets of eight.
Q4: Is the module suitable for SIL3 applications?
A4: Yes, it is designed to comply with SIL3 safety requirements under IEC 61508.
Q5: Can it be used in hazardous environments?
A5: Yes, it supports Class I Division 2 applications with proper installation conditions.
| number | describe |
|---|---|
| CPCHAS-0002 | Chassis for redundant Controller (Safety Manager A.R.T.) |
| PSU-UNI2450U | 25–28 Vdc Power supply (1200 W) – UL508 approved |
| QPP-0002 | Quad Processor Pack |
| SDI-1624 | Safe digital input module (24 Vdc, 16 channels) |
| BSN-1608 | Digital converter module for Safety sensor signals (16 channels) |
| SDOL-0424 | Safe loop-monitored digital output module (24 Vdc, 1 A, 4 channels) |
| BSDOL-04UNI | Range setting module |
| RUSIO-3224 | Remote Universal Safe IO device (32 channels, 24 Vdc) |
| FS-IOBUS-CPIOX | IO bus in extension cabinet |
| TSAI-1620M | Safe 0-20 mA and 4-20 mA analog input FTA (16 channels) |
| TSHART-1620M | Safe 0-20 mA and 4-20 mA analog input FTA with HART interface (16 channels) |
| DCOM-232/485 | RS232/485 communication FTA |
| IOTA-R24 | Redundant IO Termination Assembly |
| TERM-NAMUR-01 | NAMUR to 0-20mA analog-IN converter terminal |
| SICC-0001/L50 | System Interconnection Cable terminating on FTAs (SICC) |
| CCE-485-05/L10 | External communication cable |
| PDB-0824P | Power Distribution Board (24Vdc, 2 Amp, 8 channel) |
| PDC-CPX05 | Power Distribution Board Controller cabinet (5 Vdc, Watchdog) |
