Honeywell FS-PDC-MB24-1P heavy-duty 24VDC power distribution cable Original new

Honeywell FS-PDC-MB24-1P heavy-duty 24VDC power distribution cable Original new

Product Name:24VDC power distribution cable

Brand Name:Honeywell

Model Number:FS-PDC-MB24-1P

Country of Origin:USA

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

honeywell fs pdc mb24 1p heavy duty 24vdc power distribution cable original new-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Honeywell
Model Number:	FS-PDC-MB24-1P
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	FS-PDC-MB24-1P
Product Type	24VDC Power Distribution Cable
Compatible Models	FS-PDC-MB24-1P, FS-PDC-MB24-2P, FS-PDC-MB24-3P
Voltage Rating	24VDC Power Distribution
Cable Construction	CC600, 2 × 6 mm² industrial cable
Cable Length	145 cm (57.1 in)
Main Rail Connector	D-TAB-200-STR, 2-pole Squeeze-To-Release connector
FTA/Board Connector	Weidmuller BVZ 7.62HP/02F SN keyed connector
Connector Keying	BV/SV7.62HP KO, dedicated 24VDC keying
Dimension	Overall cable length 145 cm with compact industrial connectors
Weight	Approx. 0.45 kg (estimated based on cable size and length)
Compliance	UL, CSA approved, FM pending

Description

The FS-PDC-MB24-1P is a heavy-duty 24VDC power distribution cable engineered for reliable power transfer between the MB-0001 main power rail and connected field devices, power distribution boards, or field termination assemblies (FTAs). Designed for industrial automation and safety control systems, it provides a secure and efficient method of distributing low-voltage DC power throughout control cabinets.

As part of the FS-PDC-MB24 cable family, including FS-PDC-MB24-2P and FS-PDC-MB24-3P, this cable features high-capacity 6 mm² conductors and industrial-grade connectors optimized for continuous operation in demanding environments. The keyed connector design helps prevent incorrect wiring and simplifies installation.

With robust construction, secure locking mechanisms, and compatibility with Safety Manager infrastructure, the FS-PDC-MB24-1P contributes to improved power reliability, reduced maintenance requirements, and enhanced system availability across critical industrial applications.

Applications

Power plants: Used for distributing 24VDC power to protection relays, control panels, and auxiliary monitoring equipment.
Substations: Enables reliable low-voltage power delivery for communication devices, switchyard automation, and protection systems.
Chemical plants: Supports process control cabinets, safety instrumented systems, and field termination assemblies.
Steel mills: Provides dependable DC power connections in environments with vibration, heat, and electrical noise.
Machinery manufacturing plants: Supplies power to automation panels, robotic cells, packaging systems, and industrial controllers.

Features

Heavy-duty 6 mm² conductors for low-loss power transmission
Designed for 24VDC industrial power distribution
Compatible with MB-0001 power rail systems
Keyed connector prevents incorrect installation
Industrial locking mechanism ensures secure connection
Available in multiple cable lengths for flexible deployment
Suitable for control cabinets and field termination assemblies

Functions

Transfers 24VDC power from the main power rail to connected equipment
Connects power distribution boards and FTAs efficiently
Supports stable operation of industrial control systems
Reduces wiring complexity within automation cabinets
Enhances reliability of low-voltage power infrastructure
Facilitates safe and organized cabinet power management

FAQ

Q1: What is the primary function of the FS-PDC-MB24-1P?
A1: It transfers 24VDC power from an MB-0001 main power rail to FTAs and power distribution boards.

Q2: What cable lengths are available in the FS-PDC-MB24 series?
A2: The series includes 145 cm, 245 cm, and 325 cm versions.

Q3: Which connector is used on the FTA side?
A3: A Weidmuller BVZ 7.62HP/02F SN keyed connector is used.

Q4: Is the cable suitable for industrial automation systems?
A4: Yes, it is specifically designed for industrial control and safety system power distribution.

Q5: What advantage does the keyed connector provide?
A5: It helps prevent wiring errors and ensures correct 24VDC connection during installation.
