Overview

Brand Name:	Honeywell
Model Number:	MC-TDOR12 51309148-175
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Details
Model	MC-TDOR12
Part Number	51309148-175
Output Type	Relay Digital Output
Voltage Rating	120 Vac / 125 Vdc
Channel Type	Isolated Output
Mounting Type	HPM I/O Card File
Terminal Type	Compression Terminals
Dimensions	30.6x12.5x2cm
Weight	0.76kg
Operating Temp	0 to 60°C

Description

MC-TDOR12andMC-TDOR52series are relay-based digital output modules designed for industrial control systems requiring reliable switching of AC and DC loads. The main modelMC-TDOR12 51309148-175provides stable 120 Vac / 125 Vdc output performance, supporting secure signal transmission in critical automation environments. These modules are widely used within HPM I/O architectures for process control applications.

TheMC-TDOR12 51309148-175works alongside related variants such asMC-TDOR22andMC-TDOR62, ensuring flexible system integration across different voltage levels. Its relay-based design offers strong electrical isolation and high switching reliability, making it suitable for both continuous and high-cycle operations.

Built for demanding industrial environments,MC-TDOR12 51309148-175ensures long-term operational stability in distributed control systems. With compatibility across Honeywell-style I/O subsystems, it supports scalable expansion of digital output channels in modern automation networks.

Applications

Power plants: generator monitoring and relay protection
Substations: bus protection and switchgear control
Chemical plants: automation and safe signal handling
Steel mills: high-temperature and EMI-heavy environments
Machinery plants: automated production and robotics systems

Features

High-reliability relay switching design
Electrical isolation for safe operation
Compatible with distributed I/O architecture
Stable performance under industrial load conditions

Functions

Digital output signal switching
Load control for AC/DC circuits
Integration with process control systems
Support for redundant automation architecture

FAQ

Q1: What is MC-TDOR12 used for?
A1: It is used for relay-based digital output control in industrial automation systems.

Q2: What voltage does MC-TDOR12 support?
A2: It supports 120 Vac and 125 Vdc output switching.

Q3: Is MC-TDOR12 electrically isolated?
A3: Yes, it provides isolated relay output for safer operation.

Q4: Where can MC-TDOR12 be installed?
A4: It is installed in HPM I/O card file systems for process control.

Q5: What industries use MC-TDOR12?
A5: It is widely used in power plants, substations, and industrial manufacturing systems.

Spares

Number	Describe
MC-TDOA53	120/240 Vac Solid-State Digital Output
MC-TDOD13	3-30 Vdc Digital Output
MC-TDOD14	3-30 Vdc Digital Output
MC-TDOD22	31-200 Vdc Digital Output
MC-TDOD23	31-200 Vdc Digital Output
MC-TDOD53	3-30 Vdc Digital Output
MC-TDOD54	3-30 Vdc Digital Output
MC-TDOD62	31-200 Vdc Digital Output
MC-TDOD63	31-200 Vdc Digital Output
MC-TDON12	24 Vdc Nonisolated Digital Output
MC-TDON52	24 Vdc Nonisolated Digital Output
MC-TDOY22	24 Vdc Isolated Digital Output
MC-TDOY62	24 Vdc Isolated Digital Output
MC-TDOR12	120 Vac/125 Vdc Relay Digital Output
MC-TDOR52	120 Vac/125 Vdc Relay Digital Output
MC-TDOR22	240 Vac/125 Vdc Relay Digital Output
MC-TDOR62	240 Vac/125 Vdc Relay Digital Output
