HONEYWELL MU-TPIX12 51304084-100 Pulse Input with compression terminals Ready For Ship, China HONEYWELL MU-TPIX12 51304084-100 Pulse Input with compression terminals Ready For Ship Manufacturers, Suppliers, Factory

Overview

Brand Name:	Bently Nevada
Model Number:	MU-TPIX12 51304084-100
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Specification
Model	MU-TPIX12 51304084-100
Product Type	Field Termination Assembly (FTA)
System Compatibility	Honeywell HPM System
Function	Process signal termination & distribution
Interface	I/O Processor (IOP) compatible
Signal Type	Mixed process control signals
Mounting Type	FTA mounting channel system
Cabinet Entry	Front / rear HPM cabinet integration
Channel Capacity	Standard / wide FTA support
Wiring Method	Trough-based signal routing
Operating Temp	0°C to 50°C
Storage Temp	-20°C to 70°C
dimension	30.7x12x6.8cm
weight	0.72kg

Description

The MU-TPIX12 51304084-100 Field Termination Assembly is designed for high-reliability signal processing within Honeywell High-Performance Process Manager (HPM) systems. It provides a stable interface between field instrumentation and control-level I/O modules, ensuring accurate signal conversion and transmission in complex automation environments.

The MU-TPIX12 51304084-100 is part of the advanced FTA architecture used in HPM cabinet systems, supporting integration with I/O Processor (IOP) card files. It plays a key role in organizing process wiring, improving signal integrity, and enabling efficient cabinet-level connectivity for distributed control applications.

Together with related Honeywell FTA solutions such as analog, digital, and galvanically isolated modules, the MU-TPIX12 51304084-100 enhances system scalability, wiring efficiency, and operational stability in industrial process control networks.

Applications

Power plants: Used for generator set status monitoring and relay protection
Substations: Enables bus differential control, line protection, and switchyard signal acquisition
Chemical plants: Integrates process automation and intrinsically safe signal monitoring
Steel mills (metallurgical plants): Provides stable control in high-temperature and high-EMI environments
Machinery manufacturing plants: Used in automated production lines, robotic systems, and packaging equipment

Features

Designed for Honeywell HPM FTA cabinet architecture
Supports flexible process wiring organization
Compatible with multiple IOP card file configurations
Improves signal stability and noise resistance
Supports standard and wide FTA mounting channels
Optimized for industrial control system integration
Enhances wiring separation and safety compliance

Functions

Terminates field process control signals into HPM system
Distributes signals to I/O Processor modules
Supports structured cabinet wiring management
Improves signal integrity and reduces interference
Enables modular expansion of control architecture
Facilitates stable communication between field devices and controllers

FAQ

Q1: What is MU-TPIX12 51304084-100 used for?
A1: It is used for terminating and distributing process control signals in Honeywell HPM systems.

Q2: Is MU-TPIX12 compatible with IOP systems?
A2: Yes, it is fully compatible with Honeywell I/O Processor (IOP) card file architectures.

Q3: Where is MU-TPIX12 installed?
A3: It is installed in FTA mounting channels inside HPM control cabinets.

Q4: Does it support both standard and wide channels?
A4: Yes, it supports both standard and wide FTA mounting channel configurations.

Q5: What industries use MU-TPIX12?
A5: It is widely used in power plants, substations, chemical plants, steel mills, and manufacturing automation systems.

Spares

Number	Description
MU-TSDT02	SDI FTA—Toledo Scale Cell
MU-TSDM02	SDI FTA—Manual/Auto Station
MU-TSDU02	SDI FTA—UDC6000
MU-MASX02	Manual/Auto Station
MU-TSIA12	SI FTA—Allen-Bradley
MU-TSIM12	SI FTA—Modbus
MU-TLPA02	Power Adapter (LLMux, SDI, SI FTAs)
MU-GAIH12/82	Galvanically Isolated HLAI FTA
MU-GAIH13/83	Galvanically Isolated HLAI/STI FTA
MU-GAIH14/84	Galvanically Isolated HLAI/STI FTA
MU-GAIH22/92	Galvanically Isolated HLAI FTA
MU-GAOX02/72	Galvanically Isolated AO FTA
MU-GAOX12/82	Galvanically Isolated AO FTA
MU-GDID12/82	Galvanically Isolated 24 Vdc DI FTA
MU-GDID13/83	Galvanically Isolated 24 Vdc DI FTA
MU-GDOD12/82	Galvanically Isolated 24 Vdc DO FTA
MU-GDOL12/82	Galvanically Isolated 24 Vdc DO FTA
MU-GLFD02	Combiner Panel
MU-GMAR02	Marshalling Panel
MU-GPRD02	Galvanic Isolation Power Distribution Assembly
MU-ILDX02	Long Distance I/O Link Extender Cards/Couplers
MU-ILDX03	Long Distance I/O Link Extender Cards/Couplers
MU-IOLM02	Standard I/O Link Extender Cards/Couplers
MU-IOLX02	Standard I/O Link Extender Cards/Couplers
MU-SMAC02	Analog Output Standby Manual with case
51401926-100	Analog Output Standby Manual - Digital
MU-SMDC02	Digital Output Standby Manual with case
MU-SMDX02	Digital Output Standby Manual without case1
