Product Name: 5-port entry-level managed Ethernet switches
Brand Name: MOXA
Model Number:EDS-405A-SS-SC
Country of Origin:CHINA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
MOXA |
Model Number: |
EDS-405A-SS-SC |
Country of Origin: |
CHINA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
Delivery time in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Parameter |
Specification |
|
Manufacturer |
Moxa |
|
Product Type |
Entry-level managed Ethernet switch |
|
Total Ports |
5 |
|
Copper Ports |
3 × 10/100BaseT(X) RJ45 (auto-negotiation, auto MDI/MDI-X) |
|
Fiber Ports |
2 × 100BaseFX single-mode SC |
|
Fiber Distance |
|
|
Optical Power (TX) |
|
|
Receiver Sensitivity |
|
|
Link Budget |
|
|
Redundancy Protocols |
Turbo Ring, Turbo Chain, RSTP, STP |
|
MAC Table Size |
2 K |
|
VLANs (max.) |
64 |
|
Packet Buffer |
1 Mbit |
|
Input Voltage |
12/24/48 VDC (redundant dual inputs) |
|
Operating Voltage |
9.6 to 60 VDC |
|
Input Current |
|
|
Housing |
Metal, IP30 |
|
Dimensions |
53.6 × 135 × 105 mm (2.11 × 5.31 × 4.13 in) |
|
Weight |
650 g (1.44 lb) |
|
Operating Temperature |
-10 to 60°C (14 to 140°F) |
|
Storage Temperature |
-40 to 85°C (-40 to 185°F) |
|
Relative Humidity |
5 to 95% (non-condensing) |
|
MTBF |
|
|
Warranty |
5 years |
|
Certifications |
UL 508, UL 60950-1, ATEX, Class I Div 2, DNV-GL, NEMA TS2 |
The EDS-405A-SS-SC is a 5‑port entry‑level managed industrial Ethernet switch from Moxa, designed for reliable network connectivity in harsh industrial environments. This EDS-405A-SS-SC model features three 10/100BaseT(X) RJ45 copper ports and two 100BaseFX single‑mode fiber ports with SC connectors, enabling long‑distance transmission up to 40 km. The EDS-405A-SS-SC supports Turbo Ring and Turbo Chain redundancy protocols with recovery times under 20 ms, ensuring network resilience. Advanced management features include VLAN, QoS, IGMP snooping, and SNMP.
Factory automation and machine control networks
Oil and gas pipeline monitoring and remote sites
Power utility substation communication infrastructure
ITS (intelligent transportation systems) and traffic control
Maritime and offshore platform networks
Remote data acquisition and SCADA systems
Turbo Ring/Turbo Chain Redundancy: Recovery time < 20 ms for network resilience
Dual Fiber Ports: 100BaseFX single‑mode SC connectors support distances up to 40 km
Comprehensive Security: SNMPv3, SSH, HTTPS, port lock, and broadcast storm protection
Flexible Management: Web browser, CLI, Telnet/serial console, Windows utility, and ABC‑01 backup tool
Industrial Protocols: EtherNet/IP and Modbus TCP for seamless SCADA integration
Dual Power Inputs: 12/24/48 VDC redundant inputs with reverse polarity protection
Wide Temperature Range: -10 to 60°C (wide‑temp models available to 75°C)
Hazardous Location Ready: ATEX and Class I Division 2 certified
The EDS-405A-SS-SC operates as a Layer 2 managed switch, forwarding Ethernet frames between copper and fiber segments while providing network management, security, and redundancy functions. It supports VLAN segmentation (IEEE 802.1Q and port‑based) to isolate network traffic. QoS (IEEE 802.1p) prioritizes critical data for deterministic performance. IGMP snooping optimizes multicast traffic management. The switch offers comprehensive monitoring via RMON, port mirroring, and syslog, with alarm notifications via relay output or email.
|
Storage Kits |
|
|
ABC-01 |
Configuration backup and restoration tool for managed Ethernet switches and AWK Series wireless APs/bridges/clients, 0 to 60°C operating temperature |
|
Power Supplies |
|
|
DR-120-24 |
120W/2.5A DIN-rail 24 VDC power supply with universal 88 to 132 VAC or 176 to 264 VAC input by switch, or 248 to 370 VDC input, -10 to 60°C operating temperature |
|
DR-4524 |
45W/2A DIN-rail 24 VDC power supply with universal 85 to 264 VAC or 120 to 370 VDC input, -10 to 50°C operating temperature |
|
DR-75-24 |
75W/3.2A DIN-rail 24 VDC power supply with universal 85 to 264 VAC or 120 to 370 VDC input, -10 to 60°C operating temperature |
|
MDR-40-24 |
DIN-rail 24 VDC power supply with 40W/1.7A, 85 to 264 VAC, or 120 to 370 VDC input, -20 to 70°C operating temperature |
|
MDR-60-24 |
DIN-rail 24 VDC power supply with 60W/2.5A, 85 to 264 VAC, or 120 to 370 VDC input, -20 to 70°C operating temperature |
|
Wall-Mounting Kits |
|
|
WK-46-01 |
Wall-mounting kit, 2 plates, 8 screws, 46 x 66.8 x 2 mm |
|
Rack-Mounting Kits |
|
|
RK-4U |
19-inch rack-mounting kit |
|
Software |
|
|
MXview-50 |
Industrial network management software with a license for 50 nodes (by IP address) |
|
MXview-100 |
Industrial network management software with a license for 100 nodes (by IP address) |
|
MXview-250 |
Industrial network management software with a license for 250 nodes (by IP address) |
|
MXview-500 |
Industrial network management software with a license for 500 nodes (by IP address) |
