Product Name: PROFIBUS DP V1 Master Interface Module
Brand Name: PROSOFT
Model Number: PTQ-PDPMV1
Place of Origin: United States
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
overview
| Product Name | PROFIBUS DP V1 Master Interface Module |
| Brand Name | PFOSOFT |
| Model Number | PTQ-PDPMV1 |
| Place of Origin | USA |
| Warranty | 12 months |
| Payment Methods | T/T |
| Shipment | DHL/UPS/EMS/Fedex... |
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
| Product Name | PROSOFT PTQ-PDPMV1 PROFIBUS DP V1 Master Interface Module |
| Manufacturer | PROSOFT |
| Product Type | PROFIBUS DP V1 Master Interface Module |
| Part Number | PTQ-PDPMV1 |
| Dimensions | 4x10x25cm |
| Weight | 0.42 kg |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Condition | New & Original in Factory Packing |
| Maximum number of slave stations: | 125 |
| Baud rate: | Up to 12 Mbps |
| Power supply: | Powered from the Quantum backplane |
| Operating temperature: | 0 °C to +60 °C |
| Storage temperature: | -40 °C to +85 °C |
The PROSOFT PTQ-PDPMV1 PROFIBUS DP V1 Master Interface Module is a single-slot communication module designed for Modicon Quantum and Unity PLC systems. The PROSOFT PTQ-PDPMV1 enables reliable PROFIBUS network integration by acting as a master interface for industrial automation and process control applications. It supports efficient communication with distributed field devices, making it suitable for complex and high-performance control architectures.
The PROSOFT PTQ-PDPMV1 supports communication with up to 125 PROFIBUS DP V0/V1 slave devices and operates via the RS-485 physical layer with baud rates up to 12 Mbps, including automatic baud rate detection. The PROSOFT PTQ-PDPMV1 includes DPV1 extended diagnostics, synchronization and freeze commands, broadcast and multicast telegram handling, and PROFIdrive 3.1 parameter read/write functions. It is powered directly through the Quantum backplane and supports hot standby redundancy for dual-CPU Quantum systems. The module also includes ProSoft Configuration Builder software and FDT/DTM (comDTM) tools for configuration and device management.
The PROSOFT PTQ-PDPMV1 PROFIBUS DP V1 Master Interface Module provides high-performance and reliable PROFIBUS communication for industrial automation systems. Its support for up to 125 slave devices ensures scalability for large networks. The hot standby capability enhances system availability and redundancy in critical applications. Integrated diagnostics and configuration tools simplify commissioning and maintenance. The PROSOFT PTQ-PDPMV1 also reduces system complexity by powering directly from the Quantum backplane, eliminating the need for external power wiring.
The PROSOFT PTQ-PDPMV1 PROFIBUS DP V1 Master Interface Module is designed for industrial control environments, operating reliably at temperatures from 0 °C to +60 °C, with storage capability from -40 °C to +85 °C. The PROSOFT PTQ-PDPMV1 is suitable for installation in Quantum PLC racks and supports stable operation in factory automation, process control, and distributed control systems. Its rugged industrial design ensures dependable performance under continuous operation and typical electromagnetic industrial conditions.
Q1: What PLC platforms are compatible with the PROSOFT PTQ-PDPMV1 PROFIBUS DP V1 Master Interface Module?
A: The PROSOFT PTQ-PDPMV1 is designed for Modicon Quantum and Unity PLC systems, where it functions as a single-slot PROFIBUS DP V1 master module.
Q2: Does the PTQ-PDPMV1 require an external power supply?
A: No, the PROSOFT PTQ-PDPMV1 is powered directly via the Quantum backplane and does not require any additional external power source.
Q3: Can the PTQ-PDPMV1 PROFIBUS DP V1 Master Interface Module be used in redundant control systems?
A: Yes, the PROSOFT PTQ-PDPMV1 supports hot standby operation and is fully compatible with Quantum dual-CPU redundant architectures.
Q4: What type of network topology does the PROSOFT PTQ-PDPMV1 support?
A: The PROSOFT PTQ-PDPMV1 supports standard PROFIBUS DP networks based on RS-485 communication, suitable for multi-drop fieldbus configurations.
Q5: What tools are included for configuring the PROSOFT PTQ-PDPMV1?
A: The PROSOFT PTQ-PDPMV1 includes ProSoft Configuration Builder software along with FDT/DTM (comDTM) tools for network setup and device management.
