Product Name: K60 AS-i Compact Digital I/O Module
Brand Name: Siemens
Model Number: 3RK2200-0DQ00-0AA3
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales: |
Email: |
Whatsapp: |
Jim Pei |
| Product Name | Siemens 3RK2200-0DQ00-0AA3 K60 AS-i Compact Digital I/O Module |
| Manufacturer | Siemens |
| Product Type | K60 AS-i Compact Digital I/O Module |
| Part Number | 3RK2200-0DQ00-0AA3 |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Digital Inputs | 8 |
| I/O Configuration | 8 DI |
| Maximum Sensor Current | 200 mA |
| Number of I/O Sockets | 8 |
| Connector Type | 8 × M12 Socket (Y-II Assignment) |
| Electrical Connection | M12 Screw-Type Terminals |
| Input Circuit | PNP Transistor |
| Input Voltage Type | DC |
| Input Voltage Range | 20–30 V DC |
| Input Switching Level (High) | ≥10 V |
| Input Current (Signal "1") | Min. 6 mA |
| Input Current (Signal "0") | Max. 1.5 mA |
| AS-Interface Operating Voltage | 26.5–31.6 V |
| AS-Interface Current Consumption | Max. 270 mA |
| Sensor Supply | Via AS-Interface |
| Sensor Supply Protection | Short-circuit and overload protected |
| Sensor Supply Current | Max. 200 mA (at 40°C) |
| Ground Connection | Pin 5 of each M12 socket connected to mounting plate grounding strap |
| Status Indicators | Yellow LED (I/O), Green/Red LED (AS-i/Diagnostics) |
| Protection Rating | IP67 |
| Operating Temperature | -25°C to +85°C |
| Storage Temperature | -40°C to +85°C |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The Siemens 3RK2200-0DQ00-0AA3 K60 AS-i Compact Digital I/O Module is a compact AS-Interface (AS-i) digital input module designed for decentralized industrial automation. It features 8 digital inputs with 8 M12 sockets, supports PNP DC input signals, and provides sensor power directly through the AS-i network. With IP67 protection, integrated diagnostic LEDs, and short-circuit-protected sensor supply, the module delivers reliable field-level connectivity for machine control, conveyor systems, and factory automation applications.
Compared with similar AS-i digital I/O modules, the Siemens 3RK2200-0DQ00-0AA3 offers simplified field installation, reliable signal acquisition, and excellent environmental protection.
Q1: What is the 3RK2200-0DQ00-0AA3 used for?
A1: 3RK2200-0DQ00-0AA3 is used to collect digital input signals from field sensors in AS-Interface automation systems.
Q2: How many digital inputs does the 3RK2200-0DQ00-0AA3 provide?
A2: 3RK2200-0DQ00-0AA3 provides 8 digital input channels.
Q3: What type of input signals does the 3RK2200-0DQ00-0AA3 support?
A3: 3RK2200-0DQ00-0AA3 supports PNP DC digital input signals with an operating voltage range of 20–30 V DC.
Q4: How are field devices connected to the 3RK2200-0DQ00-0AA3?
A4: 3RK2200-0DQ00-0AA3 uses 8 M12 screw-type sockets for quick and reliable sensor connections.
Q5: Does the 3RK2200-0DQ00-0AA3 provide sensor power?
A5: 3RK2200-0DQ00-0AA3 supplies power to connected sensors through the AS-Interface network.
Q6: Does the 3RK2200-0DQ00-0AA3 include protection for sensor outputs?
A6: 3RK2200-0DQ00-0AA3 includes short-circuit and overload protection for the sensor power supply.
