Product Name: SIPLUS S7-300 CPU 314
Brand Name: Siemens
Model Number: 6AG1314-1AG14-7AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales: |
Email: |
Whatsapp: |
Jim Pei |
| Product Name | Siemens 6AG1314-1AG14-7AB0 SIPLUS S7-300 CPU 314 |
| Manufacturer | Siemens |
| Product Type | SIPLUS S7-300 CPU 314 |
| Part Number | 6AG1314-1AG14-7AB0 |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Rated Supply Voltage | 24 V DC |
| Permissible Supply Voltage | 19.2 to 28.8 V DC |
| Recommended External Protection | 2 A minimum |
| Power Failure Buffer Time | 5 ms |
| Minimum Restart Interval | 1 s |
| Rated Current Consumption | 650 mA |
| No-Load Current Consumption | Typical 140 mA |
| Typical Inrush Current | 3.5 A |
| Typical Power Dissipation | 4 W |
| Integrated Work Memory | 128 KB |
| Maximum CPU Blocks | 1,024 (DB, FC, FB) |
| Maximum Retentive Data | 64 KB |
| Flag Memory | 256 Bytes |
| Retentive Flag Memory | MB0–MB255 |
| Maximum Local Data | 32 KB per Priority Class (2 KB per Block) |
| Maximum Expansion Units | 3 |
| Communication Interface | Integrated MPI (RS-485) |
| Interface Type | RS-485 |
| MPI Transmission Rate | Up to 187.5 kbit/s |
| Maximum Alarm-S Blocks | 300 |
| Status Block Monitoring | Up to 2 Simultaneously |
| Breakpoints | 4 |
| Operating Temperature | -25 °C to +70 °C (Max. +60 °C for UL/cUL, ATEX, FM Applications) |
| Storage Temperature | -40 °C to +70 °C |
| Maximum Installation Altitude | 5,000 m |
| Certifications | CE, UL, RCM (C-TICK), KC, EAC, ATEX |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The Siemens 6AG1314-1AG14-7AB0 SIPLUS S7-300 CPU 314 is a rugged programmable logic controller (PLC) CPU designed for the SIMATIC S7-300 automation platform. Featuring 128 KB of integrated work memory, an MPI (RS-485) communication interface, and support for up to 1,024 program blocks, it delivers reliable control performance for industrial applications. As part of the SIPLUS family, the CPU is engineered for extended operating temperatures and harsh environments, making it ideal for demanding automation systems.
Compared with similar PLC CPUs, the Siemens 6AG1314-1AG14-7AB0 offers enhanced environmental durability, reliable processing performance, and seamless integration with SIMATIC S7-300 systems.
Q1: What is the 6AG1314-1AG14-7AB0 used for?
A1: 6AG1314-1AG14-7AB0 is used as the central processing unit for SIMATIC S7-300 PLC systems in industrial automation applications.
Q2: How much work memory does the 6AG1314-1AG14-7AB0 provide?
A2: 6AG1314-1AG14-7AB0 includes 128 KB of integrated work memory.
Q3: How many expansion units can the 6AG1314-1AG14-7AB0 support?
A3: 6AG1314-1AG14-7AB0 supports up to 3 expansion units for flexible system expansion.
Q4: How many program blocks can the 6AG1314-1AG14-7AB0 support?
A4: 6AG1314-1AG14-7AB0 supports up to 1,024 program blocks, including DB, FC, and FB blocks.
Q5: What is the operating voltage of the 6AG1314-1AG14-7AB0?
A5: 6AG1314-1AG14-7AB0 operates on a rated supply voltage of 24 V DC with a permissible range of 19.2 to 28.8 V DC.
Q10: What are the main benefits of the 6AG1314-1AG14-7AB0?
A10: 6AG1314-1AG14-7AB0 provides reliable PLC processing, extended temperature operation, integrated MPI communication, scalable expansion, large memory capacity, and certified performance for demanding industrial automation environments.
