Siemens 6AU1425-2AD00-0AA0 SIMOTION D425-2 DP/PN Control Unit

Siemens 6AU1425-2AD00-0AA0 SIMOTION D425-2 DP/PN Control Unit

Product Name: SIMOTION D425-2 DP/PN Control Unit

Brand Name: Siemens

Model Number: 6AU1425-2AD00-0AA0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp: +86 18020776782

Email: [email protected]

Appurtenance:

Overview
Description
Motion Integration
Specifications
Contact info
Commercial Term
About Company
FAQ
Other Products
Recommended Products

Drive-Based Motion Control for Multi-Axis Automation

Siemens 6AU1425-2AD00-0AA0 is a SIMOTION D425-2 DP/PN drive-based programmable motion controller in the BASIC performance class.

Selection checkpoint: Confirm the SIMOTION project, firmware, CompactFlash data, DRIVE-CLiQ topology and PROFIBUS/PROFINET assignments before commissioning a replacement controller.

Description

6AU1425-2AD00-0AA0 combines PLC and motion-control tasks for multi-axis machines. The D425-2 DP/PN platform provides DRIVE-CLiQ connections together with PROFIBUS, PROFINET, Ethernet, USB and configurable I/O for coordinated machine control.

A service replacement depends on the saved SIMOTION project and the installed drive topology. Record the controller firmware, CompactFlash contents, network addresses and axis assignments before hardware is exchanged, then restore and validate the machine in controlled stages.

Motion Integration

01	Multi-axis control Coordinate motion tasks for machines with multiple configured axes.

02	DRIVE-CLiQ links Connect supported SINAMICS drive components through four DRIVE-CLiQ interfaces.

03	Industrial networks Integrate PROFIBUS and PROFINET devices with documented machine addressing.

04	Project recovery Restore the approved controller project and retained machine data after service.

Specifications

Technical parameter	Value
Product type designation	SIMOTION D425-2 DP/PN
Article number	6AU1425-2AD00-0AA0
Performance class	BASIC Performance
Maximum axes	16
DRIVE-CLiQ interfaces	4
PROFIBUS interfaces	2
PROFINET connection	1 interface with 3 onboard ports
Additional interfaces	2 Ethernet and 2 USB
Integrated I/O	12 DI and 16 DI/DO
Rated supply voltage	24 V DC
Included hardware	Dual fan / battery module and battery
Manufacturer	Siemens

Contact info

CONTACT

Jim Pei

[email protected]

+86 180 2077 6782

Commercial Term

Quotation	Payment	Lead time	Shipping	Warranty
Contact us for current price and availability	T/T or agreed terms	Confirmed with the quotation	DHL, FedEx, UPS or agreed freight	12 months

About Company

SupplyPLCs supports exact-model review, product-condition confirmation and responsive industrial automation sourcing.

Share the complete order number, installed-system context and destination. Our team will coordinate availability, shipment options and available official product documentation.

FAQ

How can I confirm that 6AU1425-2AD00-0AA0 is compatible with the SIMOTION project in my machine?

Compare the exact D425-2 DP/PN order number, controller firmware, SCOUT project version, CompactFlash data and configured axis count. Review all technology objects and drive assignments before downloading anything to the replacement unit.

What should I preserve before replacing 6AU1425-2AD00-0AA0 during a planned outage?

Archive the complete SIMOTION project and record firmware, licenses, retained data, network addresses and the DRIVE-CLiQ topology. Keep a verified copy of the CompactFlash contents and document every connected drive component before disconnection.

Why can 6AU1425-2AD00-0AA0 start but fail to recognize a SINAMICS drive after restoration?

Compare the physical DRIVE-CLiQ order with the saved topology and inspect connector seating before changing project data. A missing or differently ordered drive component can prevent the restored configuration from matching the machine.

How should I investigate a PROFINET communication fault after installing 6AU1425-2AD00-0AA0?

Check the assigned device name, IP settings, port connections and controller role against the archived project. Diagnose one network segment at a time and preserve the working motion configuration while isolating the communication path.

What maintenance checks are important when the fan or battery alarm appears on 6AU1425-2AD00-0AA0?

Follow the Siemens service procedure for the supplied dual fan and battery module, preserve power and data requirements, and document the alarm state. Do not remove the controller or memory media until the project and retained-data recovery plan is confirmed.

Which engineering details should accompany an RFQ for 6AU1425-2AD00-0AA0?

Include the full order number, controller firmware, SIMOTION engineering version, axis count, CompactFlash identification, DRIVE-CLiQ topology and PROFIBUS/PROFINET roles. This lets the service spare be reviewed against the installed machine rather than only by family name.
