Product Name: SIMATIC HMI TP2200 Comfort Touch Panel
Brand Name: Siemens
Model Number: 6AV2124-0XC02-0AX0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp: +86 18020776782
Email: [email protected]
| Minimum Order Quantity | 1 Piece |
| Price | Contact for Jim |
| Packaging Details | Original new Factory Sealed |
| Delivery Time | 3-7 Days |
| Payment Terms | T/T |
| Shipping Method | DHL / FedEx / UPS / TNT |
| Supply Ability | In stock |
| Official Article Number | 6AV2124-0XC02-0AX0 |
| Manufacturer | Siemens AG |
| Product Type Designation | SIMATIC HMI TP2200 Comfort |
| Design of Display | TFT |
| Screen Diagonal | 21.5 in |
| Display Width | 495.6 mm |
| Display Height | 292.2 mm |
| Number of Colors | 16 777 216 |
| Horizontal Image Resolution | 1 920 Pixel |
| Vertical Image Resolution | 1 080 Pixel |
| MTBF Backlighting (at 25 °C) | 30 000 h |
| Type of Supply Voltage | DC |
| Rated Supply Voltage (DC) | 24 V |
| Supply Voltage Lower Limit (DC) | 19.2 V |
| Supply Voltage Upper Limit (DC) | 28.8 V |
| Current Consumption | 2.2 A |
| Starting Current Inrush I²t | 0.5 A²·s |
| Typical Active Power Input | 53 W |
| Memory Available for User Data | 24 Mbyte |
| Retentive | Yes; Back-up duration typically 6 weeks |
| Number of Industrial Ethernet Interfaces | 2; 2 ports (switch) + independent port |
| Number of RS 485 Interfaces | 1; RS 422/485 combined |
| Number of USB Interfaces | 2; USB 2.0 |
| Operating Temperature Minimum for Vertical Installation | 0 °C |
| Operating Temperature Maximum for Vertical Installation | 45 °C |
| Operating Temperature Minimum at Maximum Tilt | 0 °C |
| Operating Temperature Maximum at Maximum Tilt | 40 °C |
| Operating Temperature Minimum for Portrait Installation | 0 °C |
| Operating Temperature Maximum for Portrait Installation | 40 °C |
| Operating Temperature Minimum at Maximum Tilt, Portrait | 0 °C |
| Operating Temperature Maximum at Maximum Tilt, Portrait | 35 °C |
| Storage/Transport Temperature Minimum | −20 °C |
| Storage/Transport Temperature Maximum | 60 °C |
| Maximum Relative Humidity | 90 %; no condensation |
| Width of The Housing Front | 560 mm |
| Height of Housing Front | 380 mm |
| Mounting Cutout, Width | 542 mm |
| Mounting Cutout, Height | 362 mm |
| Overall Depth | 75 mm |
| Weight without Packaging | 7.1 kg |
| Sales | Phone/Whatsapp | |
| Jim Pei | [email protected] | +86 18020776782 |
6AV2124-0XC02-0AX0 is a Siemens SIMATIC HMI TP2200 Comfort Touch Panel with product type designation of SIMATIC HMI TP2200 Comfort. Its official product data also identifies screen diagonal of 21.5 in and display width of 495.6 mm. This SIMATIC HMI Comfort product supports dependable integration into its designated Siemens automation architecture. It is suited to engineering, system expansion, modernization, replacement, and lifecycle-maintenance projects. The exact Siemens article reference helps users maintain consistent system documentation and organized spare-parts planning. For professional sourcing and service support, 6AV2124-0XC02-0AX0 is the precisely identified product version.
What applications are suitable for 6AV2124-0XC02-0AX0?
6AV2124-0XC02-0AX0 is suited to compatible industrial automation systems, including production machinery, process equipment, infrastructure control, modernization, and lifecycle-maintenance projects.
What role does 6AV2124-0XC02-0AX0 provide in an automation system?
6AV2124-0XC02-0AX0 provides the designated Siemens hardware function for its product family and supports coordinated operation with compatible controllers, networks, operator systems, or field devices.
How does 6AV2124-0XC02-0AX0 support system maintenance?
6AV2124-0XC02-0AX0 gives engineers an exact article reference for replacement, troubleshooting, expansion, documentation, and spare-parts planning in supported installations.
What is the earliest time when you can make delivery?
We will make delivery once received your payment.
Do you provide warranty for the goods?
Yes, we offer a one-year warranty for all goods shipped from us.
Do you have branches in foreign countries?
No, but we sell to all over the world.
Are you manufactory or trading company?
Trading company.
Years of Global Experience: With over 10 years of experience in the industrial automation industry, we serve customers worldwide and have built long-term business relationships with clients across many countries and regions, including the United Kingdom, Russia, the United Arab Emirates, India, Venezuela, and more.
Professional Support Team: Our experienced team provides helpful pre-sales consultation and reliable after-sales support, helping customers select suitable products and solve purchasing concerns.
Wide Range of Brands: We supply products from many leading automation brands, covering PLCs, DCS, I/O modules, drives, motors, power supplies, communication modules, and more.
Large In-Stock Inventory: A wide selection of automation components is available from stock, including discontinued, obsolete, and hard-to-find parts, helping customers reduce sourcing time.
Honesty & Trust: We believe long-term cooperation begins with sincerity. We treat every customer with honesty, respect, responsibility, and genuine care.
Your Trusted Automation Partner: Whether you need a single replacement part, discontinued components, or products for a complete automation project, we are ready to support your needs and build a long-term partnership.
Warranty Support
Most products are covered by a warranty of up to 12 months, subject to the applicable terms and conditions. If any product-related issue occurs during the warranty period, our team will assist you and provide an appropriate solution.
Technical Documentation
Relevant datasheets and technical literature can be provided with the goods, offering useful information for product identification, installation, operation, and maintenance.
Fast Response
We understand the importance of minimizing equipment downtime. Our team responds promptly to inquiries and provides professional assistance with product information, quotations, order status, shipping, and after-sales questions.
Global Customer Service
We serve customers worldwide and provide reliable assistance from inquiry to delivery and after-sales service, ensuring clear and timely communication throughout the process.
Long-term Spare Parts Supply
We continue to source discontinued, obsolete, and hard-to-find automation parts from various brands, helping customers maintain existing equipment and reduce downtime caused by spare parts shortages.
