Product Name: SIMATIC OP270 10-inch Operator Panel
Brand Name: Siemens
Model Number: 6AV6542-0CC10-0AX0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp: +86 18020776782
Email: [email protected]
Fast response for industrial automation sourcing
| SalesJim Pei | Email[email protected] | Phone/Whatsapp+86 18020776782 |
| PARAMETER | OFFICIAL VALUE |
|---|---|
| Model Number | 6AV6542-0CC10-0AX0 |
| Current consumption (rated value) | 0.9 A |
| Memory available for user data | 2 048 kbyte |
| Interfaces/bus type | 2 x RS232, 1 x RS422, 1 x RS485 (max. 12 Mbit/s) |
| Transmission rate, max. | 12 Mbit/s |
| Recipe memory | 64 KB integrated Flash, expandable |
| Connection to controller | S5, S7-200, S7- 300/400, TI 505, Win AC, PC (TCP/IP), |
| Design of display | STN, 256 colors |
| Processor type | RISC 32-bit |
| Backup battery (optional) | Yes; optional 3.6 V |
| CF card slot | 1 x CF card slot |
| IP (at the front) | IP65 |
| IP (rear) | IP20 |
| Certifications | CE, GL, ABS, DNV, LRS, FM Class I Div. 2, UL, cULus, EX Zone |
| min. | 20 °C |
| max. | 60 °C |
| Operation, max. | 90 % |
| Configuration tool | ProTool Version 6 SP 3 or higher, or WinCC flexible Standard |
| Text objects | 10,000 text elements |
| Status/control | With SIMATIC S7 |
| Horizontal image resolution | 640 Pixel |
| Vertical image resolution | 480 Pixel |
| Number of RS 485 interfaces | 1 |
| USB port | Yes; 1 x USB |
| Type of memory | Flash / RAM |
| Memory location | CF card, Ethernet |
| Screen diagonal | 10.4 in |
| MTBF backlighting (at 25 °C) | 60 000 h |
| Number of function keys | 36 |
| Number of function keys with LEDs | 28 |
| Number of system keys | 38 |
| maximum permissible angle of inclination without | 35° |
| Backup time, min. | 3y |
| Number of online/runtime languages | 5 |
| Languages per project | 32 |
|
01
6AV6542-0CC10-0AX0 is suitable for machine visualization, operator control, process monitoring, alarms, recipes, and maintenance of installed SIMATIC HMI systems. |
02
It can also support replacement and spare-parts support for established OP270 and ProTool-based automation installations. |
|
Q · How is the product packaged?
A · Original new Factory Sealed. |
Q · What is the delivery time?
A · Normally 3–7 days. Goods are dispatched promptly after payment is received. |
|
Q · Which payment terms are accepted?
A · T/T. |
Q · Which shipping methods are available?
A · DHL / FedEx / UPS / TNT. |
|
Q · Is the item available?
A · Yes. Supply Ability: In stock. |
Q · How do you ensure product quality?
A · The product is carefully checked before delivery and is supplied with quality-focused after-sales support. |
