Siemens 6DD1600-0AF0 processor module PM16 In stock

Siemens 6DD1600-0AF0 processor module PM16 In stock

Product Name:processor module PM16

Brand Name:Siemens

Model Number:6DD1600-0AF0

Country of Origin:Germany

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

siemens 6dd1600 0af0 processor module pm16 in stock-1

Overview
Inquiry now
Specifications
Description
Applications
Control & Communication
Construction, Interfaces & Safety Features
FAQ
Spares
Recommended Products

Overview

Brand Name:	Siemens
Model Number:	6DD1600-0AF0
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Inquiry now

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	6DD1600-0AF0: High-performance SIMADYN D PM16 processor module for real-time industrial automation control and computation.
CPU Type	80C186 16-bit processor, 16 MHz clock frequency, optimized for deterministic control tasks and fast cycle execution.
Memory	128 KB RAM, battery-buffered system memory for program execution and runtime data retention.
I/O Channels	16 binary inputs and 16 binary outputs, supporting interrupt-driven signal processing and fast data exchange.
Communication	Dual serial interfaces (RS232/TTY/RS485 options), enabling system networking and external device integration.
Mounting	Rack-mounted SIMADYN D module, occupies two slots, designed for secure industrial cabinet installation.
Operating Voltage	+5 V, +15 V, -15 V internal supply rails with external 24 V support for I/O operation.
Dimensions	233.4 mm × 220 mm × 40.28 mm, compact board design suitable for modular control racks.
Weight	Approx. 0.7 kg, lightweight structure for stable mechanical installation in control cabinets.

Description

The 6DD1600-0AF0 processor module PM16 is designed for high-performance automation, regulation, and complex computing tasks within SIMADYN D control systems. It integrates a 16-bit 80C186 CPU running at 16 MHz with 128 KB RAM, enabling stable real-time control for demanding industrial applications. The module supports fast cycle processing and interrupt-driven operation for precise system response.

The 6DD1600-0AF0 works alongside SIMADYN D components such as PM16, MS3/MS31 memory modules, and related expansion interfaces, forming a scalable control architecture. It provides 16 binary inputs and 16 binary outputs for rapid process interaction, with configurable interrupt capability for time-critical events.

In addition, the 6DD1600-0AF0 supports dual serial communication interfaces and robust system diagnostics, ensuring reliable integration, maintenance, and data exchange in distributed automation environments.

Applications

Power plants: Used for generator set monitoring, real-time control, and protection relay coordination in energy systems.
Substations: Enables bus differential protection, switching control, and distributed signal acquisition for grid stability.
Chemical plants: Supports process automation, intrinsic safety monitoring, and continuous production control.
Steel mills: Provides robust logic control under high temperature, vibration, and electromagnetic interference environments.
Machinery manufacturing: Applied in automated production lines, robotics systems, and packaging machine control for precision operation.

Control & Communication

The 6DD1600-0AF0 supports real-time deterministic processing for automation, regulation, and complex control tasks within SIMADYN D systems, ensuring stable cycle execution and fast response performance.
Dual serial communication interfaces (RS232, TTY, RS485 options) enable flexible connectivity with PLC systems, host computers, operator panels, and distributed industrial networks.
Interrupt-driven processing architecture allows event-based data exchange and precise synchronization between control tasks and external communication signals.
The module supports integration with program memory and system components, ensuring scalable and coordinated communication across multi-module architectures.

Construction, Interfaces & Safety Features

The 6DD1600-0AF0 is designed as a rack-mounted dual-slot CPU module, built for secure installation in industrial control cabinets with stable mechanical fixation.
It connects to SIMADYN D system and communication buses, enabling high-speed internal data transfer and reliable multi-module coordination.
Plug-in memory modules and interface extensions support flexible configuration, maintenance, and system scalability.
Integrated watchdog monitoring and system diagnostics provide continuous hardware and software supervision for operational stability.
EMC-oriented design with shielded cabling and mandatory potential bonding ensures strong noise immunity in harsh industrial environments.
Fault handling functions such as NMI response and system error detection enhance operational safety and prevent unstable system states.

FAQ

Q1: What is the main function of 6DD1600-0AF0?
A1: It is a SIMADYN D PM16 processor module used for real-time automation, control, and high-speed computation tasks.

Q2: How much memory does 6DD1600-0AF0 support?
A2: It includes 128 KB RAM with battery-buffered storage for program and system data retention.

Q3: Does 6DD1600-0AF0 support interrupt inputs?
A3: Yes, it provides 16 binary inputs, with up to 4 configurable as interrupt-triggered channels.

Q4: What communication interfaces are available?
A4: The module supports dual serial interfaces including RS232, TTY, and RS485 options depending on configuration.

Q5: Is the module suitable for harsh industrial environments?
A5: Yes, it is designed for EMC-protected industrial use with robust diagnostics and watchdog monitoring for reliability.

Spares

Model	Model
