Siemens 6DD1600-0AK0 SIMATIC TDC CPU Module

Siemens 6DD1600-0AK0 SIMATIC TDC CPU Module

Product Name: SIMATIC TDC CPU Module

Brand Name: Siemens

Model Number: 6DD1600-0AK0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

siemens 6dd1600 0ak0 simatic tdc cpu module-1

Overview
Specifications
Commercial Terms
Contact Us
Advantages
FAQ
Why Choose Us
Major Business
Recommended Products

Overview

The Siemens 6DD1600-0AK0 SIMATIC TDC CPU Module is a high-performance CPU module designed for SIMATIC TDC automation and drive control systems. It features a 32/64-bit RISC processor, 64/128 MHz processing speed, 8 MB DRAM, 256 KB battery-buffered SRAM, 8 binary inputs, and supports STEP 7, HW Config, and CFC programming with MS5/MS51 program memory modules. Designed to execute complex open-loop and closed-loop control algorithms, the CPU module delivers fast processing, reliable data management, and stable system coordination. Its seamless integration with SIMATIC TDC platforms makes it an ideal solution for power generation, process automation, industrial drive systems, and other mission-critical control applications.

Specifications

Product Name	Siemens 6DD1600-0AK0 SIMATIC TDC CPU Module
Manufacturer	Siemens
Product Type	SIMATIC TDC CPU Module
Part Number	6DD1600-0AK0
Place of shipment	Xiamen, China
Country of origin	Germany
Processor	32/64-bit RISC Processor
Processor Clock Speed	64/128 MHz
Binary Inputs	8
Interrupt-capable Inputs	Max. 4
Rated Input Voltage	24 V DC
Input Voltage (Signal "0")	-1 to +6 V or input open-circuit
Input Voltage (Signal "1")	+13 to +33 V
Input Current (Signal "0")	0 mA
Input Current (Signal "1")	Typical 3 mA
Maximum Input Delay	20 µs
Electrical Isolation	No (only via SB60/SB61 interface modules)
Supply Voltage (+5 V)	4.75 to 5.25 V DC (typical current 1700 mA)
Supply Voltage (+15 V)	14.4 to 15.6 V DC (typical current 50 mA)
Supply Voltage (-15 V)	-15.6 to -14.4 V DC (typical current 30 mA)
External Supply Voltage	20 to 30 V DC (typical current 100 mA + binary output currents)
DRAM Capacity	8 MB (16 MB version available)
SRAM Capacity	256 KB (battery-buffered)
Typical CPU Cycle Time	0.1 ms
Typical Control Loop Execution Time	Approx. 0.5 ms
Programming Software	STEP 7 / HW Config / CFC
Program Memory Module	MS5 or MS51

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Contact Us

Sales	Email	Phone/Whatsapp
Jim Pei	[email protected]	+86 18020776782

Advantages

High-Performance RISC Processing
Powered by a 32/64-bit RISC processor, the module delivers fast execution of complex control algorithms, enabling efficient open-loop and closed-loop control for demanding industrial applications.

Fast Real-Time Control Performance
Supports rapid CPU cycle times and control loop execution, providing responsive system operation for high-speed automation, motion control, and process regulation.

Reliable Memory Architecture
Combines high-speed DRAM with battery-buffered SRAM to support efficient program execution while preserving critical operating data and diagnostics during power interruptions.

Flexible Programming and Configuration
Compatible with STEP 7, HW Config, and CFC engineering software, allowing convenient program development, configuration, and system commissioning for SIMATIC TDC applications.

Seamless SIMATIC TDC Integration
Designed specifically for SIMATIC TDC rack systems and compatible with MS5 and MS51 program memory modules, ensuring straightforward installation and dependable system integration.

Ideal for High-Performance Automation
Well suited for power generation, industrial drive control, process automation, metals processing, and other applications requiring fast, reliable, and deterministic real-time control.

FAQ

Q1: What is the 6DD1600-0AK0 used for?
A: The 6DD1600-0AK0 is a CPU module used as the central processing unit in SIMATIC TDC systems, executing automation programs and coordinating real-time control tasks.

Q2: Which programming software is compatible with the 6DD1600-0AK0?
A: The 6DD1600-0AK0 supports STEP 7, HW Config, and CFC software for programming, configuration, and commissioning of SIMATIC TDC applications.

Q3: Does the 6DD1600-0AK0 support battery-backed data retention?
A: Yes. The 6DD1600-0AK0 includes battery-buffered SRAM that preserves important operating data, diagnostics, and process information during power failures.

Q4: Which program memory modules are supported by the 6DD1600-0AK0?
A: The 6DD1600-0AK0 is designed to operate with MS5 and MS51 program memory modules, providing flexible program storage and loading options.

Q5: Is the 6DD1600-0AK0 suitable for high-speed control applications?
A: Yes. The 6DD1600-0AK0 is engineered for fast real-time processing, making it suitable for demanding open-loop and closed-loop control applications that require rapid response and precise execution.

Q6: Which industrial applications are suitable for the 6DD1600-0AK0?
A: The 6DD1600-0AK0 is widely used in power generation, process automation, industrial drive systems, metals processing, and other mission-critical automation applications requiring high-performance CPU processing.
