Product Name:3300 XL 8 mm Proximity Probes
Brand Name:Bently Nevada
Model Number:330103-00-16-10-01-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330103-00-16-10-01-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Description |
|---|---|
| Model | 330103-00-16-10-01-00 |
| Series | 3300 XL 8 mm Proximity Probe |
| Thread Type | M10 x 1 metric thread |
| Case Length | 160 mm (configurable option) |
| Unthreaded Length | 0–150 mm adjustable |
| Cable Type | 75Ω triaxial shielded cable |
| Connector Type | ClickLoc gold-plated connector |
| Operating Temp | -52°C to +177°C |
| Storage Temp | -52°C to +177°C |
| Probe Material | Stainless steel (AISI 303/304) |
| Tip Material | PPS (Polyphenylene sulfide) |
| Weight | ~0.32 kg (probe only) |
| Dimension | 8 mm probe diameter, 1–5 m system length |
The330103-00-16-10-01-003300 XL 8 mm Proximity Probe is a high-performance eddy current sensing element designed for precise vibration and position monitoring in rotating machinery. As part of the3300 XL 8 mm Proximity Transducer System, it works together with extension cables and Proximitor sensors to deliver stable and accurate displacement signals in demanding industrial environments.
Models such as330103(standard M10 x 1, no armor) and330104(armored version) ensure flexible installation options for different mechanical requirements. The system supports both static and dynamic measurements, making it suitable for turbine, compressor, and pump monitoring applications.
Built for reliability, this probe series ensures excellent signal stability, interchangeability, and compliance with industrial standards for continuous condition monitoring.
Q1: What is the main function of 330103-00-16-10-01-00?
A1: It is used for precise vibration and shaft position measurement in rotating industrial equipment.
Q2: Can it work with other 3300 XL components?
A2: Yes, it is fully compatible with 3300 XL extension cables and Proximitor sensors.
Q3: What industries commonly use this probe?
A3: It is widely used in power plants, chemical plants, steel mills, and machinery automation systems.
Q4: Is the probe suitable for harsh environments?
A4: Yes, it is designed for high-temperature, high-vibration, and EMI-intensive environments.
Q5: Does it support armored cable options?
A5: Yes, both standard and armored versions are available depending on installation requirements.
| Number | Describe |
|---|---|
| 03200006 | Silicone self-fusing tape, 9.1-meter roll (10-yard), used for connector protection, provides electrical isolation and environmental sealing, not recommended for internal machine casing use |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables, includes connector protectors and installation tools |
| 136536-01 | Connector protector adapter allowing use of pre-1998 installation tools with 75Ω ClickLoc connectors |
| 40180-02 | Connector protectors, package of 10 pairs for 3300 XL 8 mm probes and extension cables |
| 03839410 | 75Ω triaxial male connector protector for extension cables, provides environmental protection and secure connector pairing |
| 03839420 | 75Ω triaxial female connector protector for probe leads and Proximitor sensor connections, protects against environmental exposure |
| 04301007 | 3/8-24 probe lock nut with safety wire holes, includes 2 drilled holes for secure locking |
| 04301008 | M10 x 1 probe lock nut with safety wire holes, designed for secure probe installation with safety wire |
| 330153-01 | 3300 XL connector kit for 8 mm probes and extension cables, includes ClickLoc connectors, sleeves, FEP tubing, and silicone tape |
| 330153-09 | 3300 XL ETR connector kit for high-temperature applications, includes ClickLoc connectors, sleeves, high-temp FEP tubing, and silicone tape |
| 163356 | Connector Crimp Tool Kit including multi-connector inserts and installation instructions, compatible with ClickLoc systems |
