Bently Nevada 288055-01 3500/22M Transient Data Interface Module Ready For Ship, China Bently Nevada 288055-01 3500/22M Transient Data Interface Module Ready For Ship Manufacturers, Suppliers, Factory

Overview

Brand Name:	Bently Nevada
Model Number:	3500/22M 288055-01
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	3500/22M 288055-01
Product Type	Transient Data Interface (TDI) Module
Brand	Bently Nevada
System Compatibility	3500 Monitoring System
Communication Interface	Ethernet TCP/IP
Ethernet Support	10Base-T / 100Base-TX
Fiber Optic Support	Optional 100Base-FX
Front Interface	USB-B communication port
Power Consumption	10.5 Watts
Supported Channels	Up to 48 waveform channels
Operating Temperature	-30°C to +65°C
Humidity Rating	95% non-condensing
Module Dimensions	241.3 × 24.4 × 241.8 mm
I/O Module Dimensions	241.3 × 24.4 × 99.1 mm
Module Weight	0.91 kg
Rack Requirement	1 full-height front slot

Description

Bently Nevada3500/22M 288055-01Transient Data Interface (TDI) module is an advanced communication and data acquisition interface developed for the3500 Machinery Protection System. Installed directly beside the rack power supply, the module integrates rack interface functionality with high-speed transient and steady-state data collection for critical rotating equipment monitoring applications.

The3500/22M 288055-01communicates with monitoring modules such as3500/40M,3500/42M, and other M-series monitors to collect waveform, vibration, and machine condition data through Ethernet connectivity. It supports compatibility withSystem 1condition monitoring software and3500 Configuration Software, enabling efficient remote diagnostics, system configuration, and predictive maintenance management.

Designed for industrial environments requiring continuous online machinery monitoring, the3500/22M 288055-01improves operational reliability in turbines, compressors, generators, pumps, and high-speed rotating machinery across power generation, petrochemical, marine, and manufacturing industries.

Applications

Power plants:Used for turbine vibration analysis, generator monitoring, and machinery protection system communication.
Substations:Supports industrial automation data transmission and condition monitoring integration.
Chemical plants:Enables continuous process equipment diagnostics and transient data collection in hazardous environments.
Steel mills:Performs reliable machinery monitoring under high-temperature and strong electromagnetic interference conditions.
Machinery manufacturing plants:Supports automated production line diagnostics, robotic systems, and rotating equipment monitoring.
Oil & gas facilities:Applied in compressor, pump, and turbo machinery condition monitoring systems.
Marine and offshore industries:Provides continuous machinery health monitoring and remote diagnostics for critical rotating equipment.

Features

Integrated rack interface and data acquisition functionality
Supports transient and steady-state data collection
Compatible with System 1 monitoring software
Ethernet and optional fiber optic communication support
High-speed waveform data acquisition capability
Front-panel LED status indicators
USB communication interface for local configuration
Supports remote diagnostics and predictive maintenance

Functions

Collects and transmits machinery condition data
Interfaces monitoring modules with host software
Supports waveform and transient event recording
Enables remote rack configuration and diagnostics
Monitors Keyphasor and dynamic signal inputs
Provides alarm event and startup/coastdown data collection
Enhances industrial machinery protection efficiency

FAQ

Q1:What is the main purpose of the3500/22M 288055-01module?
A1:It serves as the communication and transient data interface for the 3500 monitoring system.

Q2:Which software platforms are compatible with the3500/22M 288055-01?
A2:It supports System 1 Condition Monitoring Software and 3500 Configuration Software.

Q3:Does the3500/22M 288055-01support Ethernet communication?
A3:Yes, it supports 10Base-T and 100Base-TX Ethernet communication protocols.

Q4:How many waveform channels can the3500/22M 288055-01support?
A4:The module can support waveform collection for up to 48 channels.

Q5:In which industries is the3500/22M 288055-01commonly used?
A5:It is widely used in power generation, petrochemical, oil & gas, marine, and heavy industrial machinery applications.

Spares

number	describe
288055-01	Standard Transient Data Interface Module with USB cable
123M4610	10 foot A to B USB cable
146031-01	10Base-T/100Base-TX I/O Module
146031-02	100Base-FX (Fiber Optic) I/O Module
161580	3500/22M TDI Operation and Maintenance User Guide
164466	Network Accessories Datasheet
00580441	Connector header, internal termination, 3-position, green
00580436	Connector header, internal termination, 6-position, green
111M5777	Connector header, internal termination, 2-position, green
166M2390	Connector header, push-in spring type (alternative for PN 00580436)
166M4363	Connector header, push-in spring type (alternative for PN 00580441)
146031-03	10Base-T/100Base-TX I/O Module GLD Plated
146031-04	100Base-FX (Fiber Optic) I/O Module GLD Plated
