Product Name: LOGO!Power 12 V/4.5 A Stabilized Power Supply
Brand Name: Siemens
Model Number: 6EP1322-1SH03
Place of Origin: Germany
Warranty: 12 Months
Whatsapp: +86 18020776782
Email: [email protected]
| Sales | Phone/Whatsapp | |
| Jim Pei | [email protected] | +86 18020776782 |
| Official article number | 6EP1322-1SH03 |
| Manufacturer | Siemens AG |
| Product family | LOGO!Power |
| Power supply type | Stabilized power supply |
| Input type | 1-phase AC or DC |
| Rated AC input voltage | 100–240 V AC |
| AC input voltage range | 85–264 V AC |
| DC input voltage range | 110–300 V DC |
| Wide-range input | Yes |
| Rated line frequency 1 | 50 Hz |
| Rated line frequency 2 | 60 Hz |
| Line frequency range | 47–63 Hz |
| Input current at 120 V | 1.13 A |
| Input current at 230 V | 0.61 A |
| Maximum inrush current at +25 °C | 55 A |
| Maximum I²t | 3 A²·s |
| Overvoltage resistance | 2.3 × rated input voltage for 1.3 ms |
| Minimum mains buffering | 40 ms at 187 V and rated output current |
| Built-in incoming fuse | Internal |
| Recommended circuit breaker B | From 16 A, characteristic B |
| Recommended circuit breaker C | From 10 A, characteristic C |
| Output type | Controlled, isolated DC voltage |
| Rated output voltage | 12 V DC |
| Rated output current | 4.5 A |
| Output current range | 0–4.5 A |
| Typical supplied active power | 50 W |
| Output-voltage adjustment range | 10.5–16.1 V |
| Output adjustment method | Potentiometer |
| Static total tolerance | ±3% |
| Static mains compensation | Approx. 0.1% |
| Static load balancing | Approx. 1.5% |
| Maximum residual ripple peak-to-peak | 200 mV |
| Typical residual ripple peak-to-peak | 10 mV |
| Maximum spikes peak-to-peak | 300 mV at 20 MHz bandwidth |
| Typical spikes peak-to-peak | 70 mV at 20 MHz bandwidth |
| Maximum startup delay | 0.5 s |
| Typical voltage rise time | 10 ms |
| Efficiency at rated voltage/current | Approx. 85% |
| Power loss at rated voltage/current | Approx. 10 W |
| Maximum no-load power loss | 1.9 W |
| Dynamic mains compensation | Maximum 0.2% at rated input ±15% |
| Dynamic load smoothing | Typical ±4% at 10/90/10% load step |
| Load step settling time 10→90% | Typical 1 ms |
| Load step settling time 90→10% | Typical 1 ms |
| Parallel operation | Yes |
| Maximum parallel units | 2 |
| Typical current limitation | 5.8 A |
| Maximum continuous short-circuit current | 7 A RMS |
| Short-circuit characteristic | Constant current |
| Short-circuit proof | Yes |
| Output overvoltage protection | Yes, according to EN 60950-1 |
| Primary/secondary isolation | Yes |
| Protection class | Class II, without protective conductor |
| Degree of protection | IP20 |
| Status indication | Green LED for output voltage OK |
| Operating temperature | −20 to +70 °C, natural convection |
| Derating | +55 to +70 °C: 2%/K |
| Transport temperature | −40 to +85 °C |
| Storage temperature | −40 to +85 °C |
| Humidity class | EN 60721 climate class 3K3, no condensation |
| Input terminals | L, N: one screw terminal each |
| Input conductor cross-section | 0.5–2.5 mm², solid or finely stranded |
| Output terminals | + and −: two screw terminals each |
| Output conductor cross-section | 0.5–2.5 mm² |
| Enclosure width | 72 mm |
| Enclosure height | 90 mm |
| Enclosure depth | 52.6 mm |
| Required top clearance | 20 mm |
| Required bottom clearance | 20 mm |
| Required left clearance | 0 mm |
| Required right clearance | 0 mm |
| Approximate weight | 0.25 kg |
| Side-by-side mounting | Yes |
| Installation | DIN rail EN 60715 35×7.5/15 |
| MTBF at 40 °C | 3,800,981 h |
| CE marking | Yes |
| UL/cUL approval | UL 508 / CSA C22.2 No. 107.1, File E197259 |
| cURus recognition | UL 60950 / CSA C22.2 No. 60950, File E151273 |
| ATEX approval | II 3G Ex nA IIC T3 |
| FM approval | Class I, Div. 2, Groups ABCD, T4 |
| CB approval | Yes |
| Marine approvals | GL, ABS |
| Emitted interference | EN 55022 Class B |
| Noise immunity | EN 61000-6-2 |
6EP1322-1SH03 is a Siemens LOGO!Power stabilized power supply with a wide-range single-phase AC or DC input and a controlled, isolated 12 V DC output. Its rated output is 4.5 A, with adjustable voltage from 10.5 to 16.1 V and approximately 85% efficiency under rated conditions. The compact 72 × 90 × 52.6 mm enclosure supports DIN-rail installation and side-by-side mounting for space-efficient control cabinets. This Siemens LOGO!Power supply is designed for reliable conversion and stable control-circuit power in industrial automation systems. The product combines verified protection, monitoring, and international approval characteristics in a practical modular format. For sourcing, replacement, and maintenance projects, 6EP1322-1SH03 is a clearly identified Siemens industrial power supply solution.
