Product Name: SITOP PSU100S Power Supply
Brand Name: Siemens
Model Number: 6EP1332-2BA20
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
| Product Name | Siemens 6EP1332-2BA20 SITOP PSU100S Power Supply |
| Manufacturer | Siemens |
| Product Type | SITOP PSU100S Power Supply |
| Part Number | 6EP1332-2BA20 |
| Weight | 0.3kg |
| Estimated shipping dimensions | 3.2x12.6x12.5cm |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Rated Input Voltage | 120 V AC / 230 V AC (Auto Range Switching) |
| Input Voltage Range | 85～132 V AC / 170～264 V AC |
| Input Frequency | 47～63 Hz (Rated 50/60 Hz) |
| Rated Input Current | 1.25 A (120 V AC); 0.74 A (230 V AC) |
| Inrush Current | Maximum 33 A (25°C) |
| Rated Output Voltage | 24 V DC |
| Output Voltage Adjustment Range | 22.8～28 V DC (Polypotentiometer Adjustment) |
| Rated Output Current | 2.5 A |
| Output Current Range | 0～3 A (Up to 3 A below 45°C) |
| Rated Output Power | 60 W |
| Output Voltage Accuracy | ±3% |
| Ripple Voltage | Typical 30 mV, Maximum 150 mV |
| Peak Voltage | Maximum 240 mV |
| Start-up Time | Typical 15 ms |
| Response Delay | Maximum 0.3 s |
| Hold-up Time | Minimum 20 ms |
| Typical power consumption | 10 W |
| Operating temperature | -25°C to +70°C (natural cooling) |
| Storage temperature | -40°C to +85°C |
The Siemens 6EP1332-2BA20 is a compact 60 W industrial power supply designed to provide a stable 24 VDC output for automation and control applications. It supports 120 V AC and 230 V AC input with automatic input range switching, allowing flexible operation across different power systems without manual configuration. The unit delivers up to 2.5 A of rated output current, with an adjustable output voltage from 22.8 to 28 VDC to accommodate various application requirements. Featuring low ripple, fast startup, integrated hold-up capability, and a wide operating temperature range, the Siemens 6EP1332-2BA20 provides reliable DC power for industrial control equipment and automation systems.
Converts AC input power into a regulated 24 VDC output.
Supplies stable DC power for industrial automation and control equipment.
Supports automatic input voltage range switching for simplified installation.
Provides adjustable output voltage to meet different application requirements.
Maintains stable power during short-term input interruptions through integrated hold-up capability.
Powers controllers, sensors, communication modules, and other 24 VDC industrial devices.
Compared with conventional industrial power supplies, the Siemens 6EP1332-2BA20 offers automatic input range selection, adjustable output voltage, and reliable performance in a compact design. Its stable output characteristics make it well suited for industrial automation applications.
