Product Name:Battery and Key switch Module
Brand Name:Honeywell
Model Number:FC-BKM-0001 V1.1
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Honeywell |
Model Number: |
FC-BKM-0001 V1.1 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Details |
|
Product Model |
FC-BKM-0001 / BKM-0001 V1.1 |
|
Type |
Battery & Key Switch Module |
|
System |
Safety Manager Controller |
|
Compatible Chassis |
CPCHAS-0001 / CPCHAS-0002 / CPCHAS-0003 |
|
Battery Type |
Lithium Thionyl Chloride (LS14500) |
|
Battery Voltage |
3.6 V |
|
Capacity |
>2 Ah |
|
Supply Voltage |
24 V DC |
|
Operating Temperature |
-5°C to +70°C |
|
Storage Temperature |
-40°C to +85°C |
|
Humidity |
10–95% non-condensing |
|
Dimensions |
3.5x22.5x17.5cm |
|
Weight |
0.66kg |
|
Mounting |
Controller chassis plug-in module |
|
Certifications |
CE, UL, CSA, TÜV, FM |
FC-BKM-0001 / BKM-0001 V1.1 is a dedicated Battery and Key Switch Module designed for Honeywell Safety Manager Controller chassis systems such as CPCHAS-0001, CPCHAS-0002, and CPCHAS-0003. It serves as a shared control and backup power unit for both redundant and non-redundant controller configurations.
The module integrates dual lithium battery packs, a Force Enable key switch, and a Reset key switch into a compact 19-inch system architecture. It ensures continuous backup power for system diagnostics, real-time clock retention, and configuration data stability during power interruption.
Engineered for high-reliability industrial automation, FC-BKM-0001 supports hot-swappable operation without process interruption, making it suitable for safety-critical environments requiring stable control and secure operational management.
Q1: What is FC-BKM-0001 used for?
A1: It is used as a battery and key switch module for Safety Manager controller systems.
Q2: Does BKM-0001 support hot swapping?
A2: Yes, it can be replaced during operation without interrupting the system.
Q3: What type of batteries are used in this module?
A3: It uses non-rechargeable lithium thionyl chloride AA batteries.
Q4: What is the role of the Force Enable switch?
A4: It enables or disables software-controlled forcing of I/O signals.
Q5: What happens if the battery is removed?
A5: The system will indicate a battery error and maintain diagnostic status via LED indication.
| number | describe |
|---|---|
| CPU1 | the processor module of the first Control Processor |
| QPP-0002 | Quad Processor Pack |
| COM1.1 | the first communication module of the first Control Processor |
| USI-0002 | Universal Safety Interface |
| FX-USI-0002 | Universal Safety Interface |
| BLIND-COM | Dummy Communication Module |
| COM1.2 | the second communication module of the first Control Processor |
| PSU1 | the power supply module of the first Control Processor |
| PSU-240516 | Power Supply Unit 24/5 V DC, 16A |
| BKM | the battery and key switch module of Control Processor(s) |
| BKM-0001 | Battery and Key switch Module |
| CPU2 | the processor module of the second Control Processor |
| QPP-0002 | Quad Processor Pack |
