Product Name: SITOP RED1200 24/48 V DC 40 A Redundancy Module
Brand Name: Siemens
Model Number: 6EP4347-7RB00-0AX0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp: +86 18020776782
Email: [email protected]
| Sales | Phone/Whatsapp | |
| Jim Pei | [email protected] | +86 18020776782 |
| Official article number | 6EP4347-7RB00-0AX0 |
| Manufacturer | Siemens AG |
| Product family | SITOP RED1200 |
| type of the power supply network | DC voltage |
| at DC | 12 ... 48 V |
| at DC | 10 ... 58 V |
| voltage curve at output | Controlled DC voltage |
| number of outputs | 1 |
| output voltage at DC rated value | 24 V |
| formula for output voltage | Vin - approx. 0.6 V |
| at output 1 at DC rated value | 24 V |
| product function output voltage adjustable | No |
| rated value | 40 A |
| bridging of equipment | No |
| efficiency in percent | 97.5 % |
| at rated output voltage for rated value of the output | 25 W |
| during no-load operation maximum | 0.1 W |
| galvanic isolation between input and output | No |
| operating resource protection class | Class III |
| protection class IP | IP20 |
| CE marking | Yes |
| UL approval | Yes; cULus-Listed (UL 508, CSA C22.2 No. 107.1), File E197259 |
| CSA approval | Yes; CSA C22.2 No. 62368-1 |
| cCSAus, Class 1, Division 2 | No |
| ATEX | No |
| IECEx | No |
| NEC Class 2 | No |
| ULhazloc approval | No |
| FM registration | No |
| certificate of suitability shipbuilding approval | No |
| American Bureau of Shipping Europe Ltd. (ABS) | No |
| French marine classification society (BV) | No |
| DNV GL | No |
| Lloyds Register of Shipping (LRS) | No |
| Nippon Kaiji Kyokai (NK) | No |
| for emitted interference | EN 61000-6-3 |
| for interference immunity | EN 61000-6-2 |
| during operation | -30 ... +70 °C; with natural convection |
| during transport | -40 ... +85 °C |
| during storage | -40 ... +85 °C |
| environmental category according to IEC 60721 | Climate class 3K3, 5 … 95% no condensation |
| type of electrical connection | push-in terminals |
| at input | In1, In2: each for 0.75 ... 16 mm² |
| at output | Out1: 0.75 ... 16 mm² |
| width of the enclosure | 45 mm |
| height of the enclosure | 135 mm |
| depth of the enclosure | 125 mm |
| top | 45 mm |
| bottom | 45 mm |
| left | 0 mm |
| right | 0 mm |
| net weight | 0.51 kg |
| product feature of the enclosure housing can be lined up | Yes |
| fastening method | Snaps onto DIN rail EN 60715 35x7.5/15 |
| MTBF at 40 °C | 6 100 000 h |
| other information | Specifications at rated input voltage and ambient temperature +25 °C (unless |
6EP4347-7RB00-0AX0 is a Siemens SITOP RED1200 24/48 V DC 40 A Redundancy Module documented with 24/48 V DC input and output, 40 A total current, and two 20 A power-supply paths. These verified characteristics identify the correct hardware for its designated Siemens automation environment. The product performs its assigned role within compatible industrial control, communication, drive, or power architectures. It supports structured engineering, commissioning, and maintenance workflows. Clear Siemens article identification helps technicians source the correct component for replacement and lifecycle service. For professional automation projects, 6EP4347-7RB00-0AX0 provides a dependable, product-specific solution for compatible installations.
