Siemens 6ES7132-0BH00-0XB0 SIMATIC DP ET 200L digital output module In stock

Siemens 6ES7132-0BH00-0XB0 SIMATIC DP ET 200L digital output module In stock

Product Name:SIMATIC DP ET 200L digital output module

Brand Name:Siemens

Model Number:6ES7132-0BH00-0XB0

Country of Origin:Germany

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

siemens 6es7132 0bh00 0xb0 simatic dp et 200l digital output module in stock-1

Overview
Contact us
Specifications
Description
Applications
Environmental Strength
Environment and Certification
FAQ
Spares
Recommended Products

Overview

Brand Name:	Siemens
Model Number:	6ES7132-0BH00-0XB0
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact us

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	6ES7132-0BH00-0XB0, SIMATIC DP ET 200L Digital Output Module
Product Type	Digital Output Module: 16-channel electronic output module for distributed I/O control
Digital Outputs	16 outputs, 24 V DC, maximum 0.5 A per channel
Communication	PROFIBUS DP interface, transmission rate up to 1.5 Mbit/s
Protection Features	Electronic short-circuit protection, reverse polarity protection, galvanic isolation
Switching Performance	Maximum switching frequency 100 Hz (resistive load), 0.5 Hz (inductive load)
Diagnostics	Bus fault LED, output status LEDs, power supply monitoring LED, diagnostic functions
Degree of Protection	IP20 according to EN 60529
Operating Temperature	0°C to +60°C (horizontal mounting)
Connection Method	Screw-type and spring-loaded terminals, supports 2-, 3-, and 4-wire connections
Dimensions	145 × 60 × 60.5 mm
Weight	Approx. 130 g

Description

The Siemens 6ES7132-0BH00-0XB0 is a reliable SIMATIC DP ET 200L digital output module engineered for efficient distributed automation systems. Featuring 16 digital outputs with 24 V DC / 0.5 A output capacity, it delivers dependable signal switching for industrial control applications. Compatible with the ET 200L platform, 6ES7132-0BH00-0XB0 helps optimize machine control while maintaining stable communication over PROFIBUS DP networks.

Designed for long-term industrial operation, 6ES7132-0BH00-0XB0 incorporates electronic short-circuit protection, diagnostic LEDs, galvanic isolation, and configurable wiring through screw or spring terminals. Its compact structure simplifies installation and maintenance while supporting fast response times and reliable output performance in demanding production environments.

As part of the Siemens SIMATIC ET 200L distributed I/O family, 6ES7132-0BH00-0XB0 integrates seamlessly with PLC-based automation systems. It is widely applied in manufacturing, process industries, material handling, energy facilities, and factory automation projects requiring dependable digital output control.

Applications

Power plants: Controls digital actuators, relay outputs, and auxiliary equipment within power generation systems.
Substations: Supports breaker control, switchgear automation, and remote digital output management.
Chemical plants: Operates valves, pumps, and process actuators with stable distributed I/O communication.
Steel mills: Performs reliable output switching for conveyors, furnaces, and heavy industrial machinery.
Machinery manufacturing plants: Drives sensors, solenoids, indicator lamps, and automated production equipment.
Water treatment facilities: Controls pumps, dosing systems, and motorized valves for continuous plant operation.

Environmental Strength

Designed for reliable continuous operation in demanding industrial environments.
Operates within ambient temperatures from 0°C to +60°C under horizontal installation.
Supports relative humidity from 5% to 95% without condensation.
Tested for vibration resistance according to IEC 60068-2-6.
Shock-resistant in accordance with IEC 60068-2-27 for industrial applications.
Galvanic isolation minimizes electrical interference between field devices and communication circuits.
Supports long cable distances of up to 1000 m shielded for flexible installation.
Compact IP20 enclosure is ideal for protected electrical control cabinets.

Environment and Certification

Complies with Siemens industrial quality standards for distributed automation systems.
PROFIBUS DP communication ensures reliable integration with SIMATIC controllers.
Reverse polarity protection enhances operational safety during installation.
Electronic short-circuit protection improves system reliability and reduces maintenance requirements.
Isolation tested at 500 V DC for dependable electrical protection.
Diagnostic LEDs simplify troubleshooting and maintenance procedures.
Supports standard industrial wiring methods using screw or spring terminals.
Suitable for long-term operation in factory automation, process control, and industrial machinery.

FAQ

Q1: What is the Siemens 6ES7132-0BH00-0XB0 used for?
A1: It is a 16-channel digital output module designed for ET 200L distributed I/O systems to control industrial field devices.

Q2: How many digital outputs does the 6ES7132-0BH00-0XB0 provide?
A2: The module provides 16 digital outputs, each supporting 24 V DC with up to 0.5 A output current.

Q3: Which communication protocol does this module support?
A3: It communicates through the PROFIBUS DP network with transmission speeds up to 1.5 Mbit/s.

Q4: Does the module include diagnostic and protection functions?
A4: Yes. It features diagnostic LEDs, electronic short-circuit protection, reverse polarity protection, and galvanic isolation.

Q5: Which industries commonly use the 6ES7132-0BH00-0XB0?
A5: It is widely applied in power generation, manufacturing, chemical processing, steel production, water treatment, and general industrial automation systems.
