Product Name: 3300 NSv Proximity Probes
Brand Name: Bently Nevada
Model Number: 330905-00-03-10-02-00
Place of Origin: United States
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
overview
| Product Name | 3300 NSv Proximity Probes |
| Brand Name | Bently Nevada |
| Model Number | 330905-00-03-10-02-00 |
| Place of Origin | USA |
| Warranty | 12 months |
| Payment Methods | T/T |
| Shipment | DHL/UPS/EMS/Fedex... |
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
The BENTLY NEVADA 330905-00-03-10-02-00 3300 NSv Proximity Probes is a compact, high-precision eddy current proximity probe designed for non-contact measurement of shaft vibration, displacement, and position in rotating machinery. As part of the 3300 NSv series, it is optimized for installations where space is limited while maintaining high performance and reliability.
This probe features robust construction, fast response time, and excellent environmental resistance, making it ideal for demanding industrial monitoring applications.
The BENTLY NEVADA 330905-00-03-10-02-00 3300 NSv Proximity Probes is part of the 3300 NSv proximity probe series and features a high-precision 8 mm probe diameter (±0.01 mm) with a linear measurement range of 0.08–2.5 mm. It offers a fast response time of less than 2.5 μs signal latency and operates within a frequency range of 0.5–12 kHz (±3 dB). Designed for harsh environments, it supports an operating temperature range from -50°C to +150°C and provides IP67 waterproof protection. The probe is equipped with a fluoropolymer jacket cable featuring 90% shielding coverage and uses a miniature coaxial ClickLoc connector with gold-plated contacts for reliable signal transmission. It also delivers high vibration tolerance of up to 15g peak (2–5000 Hz), includes an M10×1 precision thread for secure installation, and maintains a minimum cable bend radius of 25 mm.
| Product Name | BENTLY NEVADA 330905-00-03-10-02-00 3300 NSv Proximity Probes |
| Manufacturer | BENTLY NEVADA |
| Product Type | 3300 NSv Proximity Probes |
| Part Number | 330905-00-03-10-02-00 |
| Dimensions | 1.8x1.6x112cm |
| Weight | 0.04kg |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Condition | New & Original in Factory Packing |
| Unthreaded Length Option | 0 mm |
| Overall Case Length Option | 30 mm |
| Total Length Option | 1.0 meter (39 in) |
| Connector and Cable-Type Option | Miniature coaxial ClickLoc connector standard cable |
| Agency Approval Option | Not required |
| Operating Temp Range | -50°C to +150°C |
| Cable Material | Fluoropolymer jacket with 90% shielding coverage |
| Vibration Tolerance | 15g peak @ 2-5000 Hz |
| IP Rating | IP67 waterproof protection |
| Response Time | <2.5μs signal latency |
| Frequency Range | 0.5-12 kHz (±3dB) |
| Probe Diameter | 8mm ±0.01mm precision |
| Thread Pitch | M10X1 with 1.6μm surface finish |
| Cable Bend Radius | 25mm minimum |
| Termination | Gold-plated contacts (0.8μm thickness) |
| Axial Gap Measurement | 0.08-2.5mm linear range |
The BENTLY NEVADA 330905-00-03-10-02-00 3300 NSv Proximity Probes is widely used in:
Q1: What is the measurement range of the BENTLY NEVADA 330905-00-03-10-02-00 3300 NSv Proximity Probes?
A: The 330905-00-03-10-02-00 provides a linear measurement range of 0.08 to 2.5 mm, suitable for precise shaft monitoring.
Q2: What makes the BENTLY NEVADA 330905-00-03-10-02-00 3300 NSv Proximity Probes suitable for compact installations?
A: Its compact design and small probe size make it ideal for tight spaces where standard probes may not fit.
Q3: What type of connector is used in the BENTLY NEVADA 330905-00-03-10-02-00 3300 NSv Proximity Probes?
A: It uses a Miniature coaxial ClickLoc connector with gold-plated contacts for reliable signal transmission.
Q4: Does the BENTLY NEVADA 330905-00-03-10-02-00 3300 NSv Proximity Probes require contact with the shaft?
A: No, it uses non-contact eddy current technology to measure shaft movement accurately.
