Product Name:SIMATIC DP electronic output module
Brand Name:Siemens
Model Number:6ES7132-1BH00-0XB0
Country of Origin:Germany
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Siemens |
Model Number: |
6ES7132-1BH00-0XB0 |
Country of Origin: |
Germany |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Specification |
|---|---|
| Product Model | The 6ES7132-1BH00-0XB0 is a SIMATIC DP electronic output block for ET 200L systems, designed for reliable 16-channel 24 V DC digital signal control in distributed automation networks. |
| Output Channels | Provides 16 digital outputs, enabling flexible multi-device control in industrial process and machine automation applications. |
| Rated Output | Supports 24 V DC output voltage with up to 0.5 A per channel for stable field device switching performance. |
| Protection Function | Integrated short-circuit protection and inductive voltage limitation ensure safe operation under electrical fault conditions. |
| Communication | Operates via PROFIBUS DP interface with support for slave-to-slave communication and system diagnostics. |
| Isolation | Optical isolation between PROFIBUS DP and output channels ensures electrical safety and noise resistance. |
| Switching Performance | Supports high-speed switching with up to 100 Hz resistive load frequency for fast response control systems. |
| Dimension | 145 mm width × 60 mm height × 60.5 mm depth, optimized for ET 200L rack installation. |
| Weight | Approximately 0.13 kg, lightweight design suitable for compact distributed I/O assemblies. |
The 6ES7132-1BH00-0XB0 is a Siemens SIMATIC DP electronic output module designed for ET 200L distributed I/O systems, delivering reliable 16-channel digital output control for industrial automation applications. It operates on a 24 V DC supply and supports up to 0.5 A per channel, ensuring stable switching performance for field devices such as relays, indicators, and actuators.
The 6ES7132-1BH00-0XB0 integrates short-circuit protection, diagnostic LEDs, and optocoupler isolation between PROFIBUS DP and output circuits, improving system safety and operational transparency. Its compact design enables flexible cabinet installation while maintaining high electrical efficiency and durability.
Widely used in Siemens ET 200L PROFIBUS DP networks, the module supports dependable signal distribution, fast response switching, and robust operation in demanding industrial environments such as process control and manufacturing automation systems.
Power plants: Used for generator set status monitoring and relay protection in distributed control systems.
Substations: Enables switchgear control, signal acquisition, and bus monitoring in power distribution networks.
Chemical plants: Supports process automation and safe control of field actuators in hazardous environments.
Steel mills: Provides reliable digital control under high temperature and strong electromagnetic interference conditions.
Machinery manufacturing plants: Used in automated production lines, robotics systems, and packaging equipment control.
Q1: What is the main function of 6ES7132-1BH00-0XB0?
A1: It provides 16-channel digital output control for ET 200L distributed automation systems.
Q2: What is the output rating of this module?
A2: Each channel supports 24 V DC output with a maximum load of 0.5 A.
Q3: Does 6ES7132-1BH00-0XB0 support diagnostics?
A3: Yes, it includes diagnostic LEDs and PROFIBUS DP-based fault detection.
Q4: Is the module protected against electrical faults?
A4: Yes, it features short-circuit protection and inductive voltage limitation.
Q5: Where is this module commonly used?
A5: It is widely used in power plants, substations, chemical plants, steel mills, and industrial manufacturing systems.
|
