Product Name: SIMATIC DP ET 200S Digital Output Electronic Module
Brand Name: Siemens
Model Number: 6ES7132-4BB01-0AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales: |
Email: |
Whatsapp: |
Jim Pei |
| Product Name | Siemens 6ES7132-4BB01-0AB0 SIMATIC DP ET 200S Digital Output Electronic Module |
| Manufacturer | Siemens |
| Product Type | SIMATIC DP ET 200S Digital Output Electronic Module |
| Part Number | 6ES7132-4BB01-0AB0 |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Number of Digital Outputs | 2 |
| Output Type | 24 V DC Digital Output |
| Module Width | 15 mm |
| Package Quantity | 5 Modules per Pack |
| Rated Load Voltage (L+) | 24 V DC |
| Reverse Polarity Protection | Yes |
| Input Current (L+, no load) | Max. 5 mA per channel |
| Backplane Bus Current | Max. 10 mA @ 3.3 V DC |
| Typical Power Loss | 0.4 W |
| Address Space (Packed) | 2 bits |
| Address Space (Unpacked) | 1 byte |
| Short-circuit Protection | Yes |
| Short-circuit Response Threshold | Approx. 1.5 A |
| Inductive Shutdown Voltage Limitation | -55 to -60 V |
| Lamp Load | Max. 2.5 W |
| Load Resistance | 48 Ω – 3.4 kΩ |
| Output Voltage ("1") | Minimum L+ (-1 V) |
| Rated Output Current | 0.5 A per channel |
| Output Current Range | 7 mA – 600 mA |
| Residual Current ("0") | Max. 0.3 mA |
| Output Delay (0 → 1) | Max. 100 μs |
| Output Delay (1 → 0) | Max. 400 μs |
| Maximum Switching Frequency | 100 Hz (resistive), 2 Hz (inductive), 10 Hz (lamp load) |
| Maximum Module Output Current | 1 A |
| Maximum Cable Length (Shielded) | 1000 m |
| Maximum Cable Length (Unshielded) | 600 m |
| Isolation Voltage | 500 V DC |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The Siemens 6ES7132-4BB01-0AB0 SIMATIC DP ET 200S Digital Output Electronic Module is a compact digital output module designed for the SIMATIC ET 200S distributed I/O system. It provides 2 digital 24 VDC output channels with a rated output current of 0.5 A per channel, offering reliable switching performance for industrial automation applications. Featuring short-circuit protection, fast response times, and long cable support, the module ensures dependable control of field devices while minimizing installation space with its 15 mm-wide design.
Compared with similar ET 200S digital output modules, the 6ES7132-4BB01-0AB0 provides compact installation, reliable output protection, and stable switching performance for industrial control systems.
Q1: What is the 6ES7132-4BB01-0AB0 used for?
A1: 6ES7132-4BB01-0AB0 is used to control 24 VDC field devices such as relays, solenoid valves, indicator lights, and actuators in ET 200S distributed I/O systems.
Q2: How many output channels does the 6ES7132-4BB01-0AB0 provide?
A2: 6ES7132-4BB01-0AB0 provides 2 digital output channels.
Q3: What is the rated output current of the 6ES7132-4BB01-0AB0?
A3: 6ES7132-4BB01-0AB0 delivers 0.5 A per channel, with a maximum module output current of 1 A.
Q4: Does the 6ES7132-4BB01-0AB0 include short-circuit protection?
A4: 6ES7132-4BB01-0AB0 includes integrated short-circuit and reverse polarity protection for improved operational safety.
Q5: What load voltage does the 6ES7132-4BB01-0AB0 require?
A5: 6ES7132-4BB01-0AB0 operates with a 24 VDC rated load voltage.
Q6: What is the module width of the 6ES7132-4BB01-0AB0?
A6: 6ES7132-4BB01-0AB0 features a compact 15 mm-wide housing for space-efficient installation.
