Siemens 6ES7132-6BF00-0CA0 SIMATIC ET 200SP Digital Output Module

Siemens 6ES7132-6BF00-0CA0 SIMATIC ET 200SP Digital Output Module

Product Name: SIMATIC ET 200SP Digital Output Module

Brand Name: Siemens

Model Number: 6ES7132-6BF00-0CA0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

siemens 6es7132 6bf00 0ca0 simatic et 200sp digital output module-1

Overview
Specifications
Commercial Terms
Overview
Features
Product Applications
Why Choose US
Other Products
Recommended Products

Contact Info

Sales:	Email:	Whatsapp:
Jim Pei	[email protected]	+86 18020776782

Specifications

Product Name	Siemens 6ES7132-6BF00-0CA0 SIMATIC ET 200SP Digital Output Module
Manufacturer	Siemens
Product Type	SIMATIC ET 200SP Digital Output Module
Part Number	6ES7132-6BF00-0CA0
Place of shipment	Xiamen, China
Country of origin	Germany
Number of Digital Outputs	8 channels
Output Voltage	24 V DC
Rated Output Current	0.5 A per channel
Maximum Module Current	4 A
Short-Circuit Protection	Yes
Wire Break Diagnostics	Supported
Diagnostic Function	Supported
Redundancy Support	Yes (parallel switching of two outputs for redundant load control)
Supply Voltage	24 V DC
Permissible Voltage Range	19.2–28.8 V DC
Reverse Polarity Protection	Yes
Power Consumption	28 mA
Typical Power Loss	1 W
Address Space	Max. 8 bytes (2 channels per submodule + QI information)
Inductive Load Shutdown Voltage Limitation	Typ. L+ (-50 V)
Output Switching Frequency	Resistive load: max. 100 Hz; Inductive load: max. 2 Hz; Lamp load: max. 10 Hz
Output Delay Time	OFF→ON: approx. 50 µs; ON→OFF: approx. 100 µs
Cable Length	Shielded: max. 1000 m; Unshielded: max. 600 m
Isolation Test Voltage	707 V DC
Operating Temperature	Horizontal: -30 to 60 °C; Vertical: -30 to 50 °C
Maximum Installation Altitude	5000 m above sea level

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Overview

The Siemens 6ES7132-6BF00-0CA0 SIMATIC ET 200SP Digital Output Module is a compact and high-performance digital output module designed for the Siemens ET 200SP distributed I/O system. It provides 8 channels of 24 VDC transistor outputs with a rated current of 0.5 A per channel, enabling reliable control of industrial actuators and field devices. Featuring integrated diagnostics, short-circuit protection, redundancy support, and fast switching performance, the module delivers a flexible and dependable solution for modern industrial automation and distributed control applications.

Features

Designed for Siemens SIMATIC ET 200SP distributed I/O systems
Provides 8 digital output channels with 24 VDC transistor outputs
Rated output current of 0.5 A per channel
Supports maximum module current of 4 A
Integrated short-circuit protection for enhanced system safety
Supports wire break and module diagnostic functions
Supports redundant load control through parallel switching of two outputs
Operates with 24 VDC supply voltage
Supports a wide voltage range of 19.2–28.8 VDC
Integrated reverse polarity protection
Low power consumption of 28 mA
Fast output switching with approximately 50 μs ON delay and 100 μs OFF delay
Supports resistive, inductive, and lamp load applications
Supports long-distance field wiring up to 1000 m with shielded cables
Compact ET 200SP design for space-saving installations
Suitable for high-altitude installations up to 5000 m above sea level

Product Applications

The Siemens 6ES7132-6BF00-0CA0 ET 200SP Digital Output Module is widely used in distributed automation systems requiring reliable digital control of field devices. Typical applications include manufacturing equipment, assembly lines, packaging systems, conveyor systems, robotic cells, machine tools, process automation, and factory control systems.

The module is ideal for controlling solenoid valves, contactors, relays, indicator lamps, actuators, and other 24 VDC industrial devices. With integrated diagnostics, redundancy capability, and robust switching performance, it provides a reliable output expansion solution for OEM machinery, production facilities, and industrial automation systems requiring high availability and efficient distributed I/O management.
