Siemens 6ES7133-0BL00-0XB0 SIMATIC DP ET 200B 16DI/16DO Digital Electronic Module

Siemens 6ES7133-0BL00-0XB0 SIMATIC DP ET 200B 16DI/16DO Digital Electronic Module

Product Name: SIMATIC DP ET 200B 16DI/16DO Digital Electronic Module

Brand Name: Siemens

Model Number: 6ES7133-0BL00-0XB0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

Overview
Product Parameters
Commercial Terms
Contact Us
Why Choose US
Major Business
Product Feature
FAQ
Recommended Products

Overview

The Siemens 6ES7133-0BL00-0XB0 SIMATIC DP ET 200B 16DI/16DO Digital Electronic Module is a digital input/output module designed for the SIMATIC DP ET 200B distributed I/O system. It provides 16 digital inputs and 16 digital outputs, all operating at 24 V DC, with output currents of up to 0.5 A per channel. Supporting PROFIBUS DP communication at speeds up to 12 Mbit/s, the module offers fast signal processing, flexible wiring options, and reliable industrial performance for distributed automation applications.

Product Parameters

Product Name	Siemens 6ES7133-0BL00-0XB0 SIMATIC DP ET 200B 16DI/16DO Digital Electronic Module
Manufacturer	Siemens
Product Type	SIMATIC DP ET 200B 16DI/16DO Digital Electronic Module
Part Number	6ES7133-0BL00-0XB0
Place of shipment	Xiamen, China
Country of origin	Germany
Digital Inputs	16 × 24 V DC
Digital Outputs	16 × 24 V DC / 0.5 A
Rated Supply Voltage	24 V DC
Supply Voltage Range	18.5 to 30.2 V DC
Logic Current Consumption	Typical 85 mA
Sensor Current Consumption	Max. 1 A
Power Dissipation	Max. 5.5 W
Required Terminal Block	TB2/DC, TB2-4/DC, TB4/DC, TB4-4/DC
Input Signal Voltage	0: -30 to +5 V, "1": 13 to 30 V
Input Current	Typical 4 mA @ 24 V DC
Input Delay	Max. 3 ms
Output Voltage	24 V DC
Output Current	0.5 A per channel
Residual Output Current	Max. 1 mA
Output Delay	20 μs (ON), 0.5 ms (OFF)
Inductive Load Protection	Shutdown Voltage Limited to -55 V
Maximum Switching Frequency	1000 Hz (Resistive Load), 0.5 Hz (Inductive Load), 8 Hz (Lamp Load)
Total Output Current	Max. 2 A per Group
Maximum Cable Length	100 m (Unshielded)
Supported Sensors	2-Wire Sensors
Maximum Sensor Leakage Current	1.5 mA
Communication Protocol	PROFIBUS DP
Maximum Transmission Rate	12 Mbit/s
Protection Rating	IP20
Operating Temperature	0 to +60 °C (Horizontal Installation)
Relative Humidity	15–95% RH
Vibration Resistance	IEC 60068-2-6
Shock Resistance	IEC 60068-2-27, 15 g / 11 ms
Connection Method	Screw-Type or Spring-Loaded Terminals (3- or 4-Wire)

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Contact Us

Sales:	Email:	Whatsapp:
Jim Pei	[email protected]	+86 18020776782

Why Choose US

✔ Genuine Industrial Automation Products
✔ Strict Quality Inspection Before Shipment
✔ Competitive Prices & Flexible Quotations
✔ Large Inventory with Fast Global Shipping
✔ 12-Month Warranty on Eligible Products
✔ Professional Technical & After-Sales Support
✔ Inquiry Response Within 1 Hour
✔ Secure Packaging for International Shipping
✔ Trusted Supplier for PLC, DCS, HMI, and Industrial Control Systems

Major Business

ABB: Industrial robot parts of DSQC series,Bailey INFI90, DCS
Honeywell: 51/MU/MC/TC/CC ...
Triconex: 3008/3511/3625/3664/3721/3700A..
Bently Nevada: 3500/3300/330180-Cable..
Foxboro: FBM203/204/217/231, FCP240/270
Woodward: SPC valve position controller, PEAK15 digital controller
Siemens: 6DD/6DP/6ES5/6DR/6GK Series
Westinghouse Series: 1C/5X ...
General electric: IC693/IC697/IC695/DS200..
Schneider: 140 Series

Product Feature

16 Digital Inputs and 16 Digital Outputs
Provides 16 × 24 V DC digital inputs and 16 × 24 V DC digital outputs for efficient field device control.
High-Speed Signal Processing
Features input delays of up to 3 ms and output response times as fast as 20 μs for responsive control.
Reliable Output Performance
Delivers up to 0.5 A per output channel with a maximum total output current of 2 A per group.
PROFIBUS DP Communication
Supports PROFIBUS DP communication with transmission rates up to 12 Mbit/s for reliable distributed automation.
Flexible Wiring Options
Compatible with both screw-type and spring-loaded terminal blocks in 3-wire or 4-wire configurations.
Built-In Load Protection
Includes inductive load protection with shutdown voltage limited to -55 V for enhanced output reliability.
Wide Industrial Compatibility
Supports 2-wire sensors and cable lengths up to 100 meters for flexible field installation.
Rugged Industrial Design
Designed with IP20 protection and resistance to vibration and shock for dependable operation in industrial environments.

FAQ

---What is the 6ES7133-0BL00-0XB0 used for?
6ES7133-0BL00-0XB0 is used to acquire digital input signals and control digital output devices in SIMATIC DP ET 200B distributed I/O systems.

---How many digital inputs and outputs does the 6ES7133-0BL00-0XB0 provide?
6ES7133-0BL00-0XB0 provides 16 digital inputs and 16 digital outputs.

---What is the output current of the 6ES7133-0BL00-0XB0?
6ES7133-0BL00-0XB0 delivers up to 0.5 A per output channel with a maximum of 2 A per output group.

---What communication protocol does the 6ES7133-0BL00-0XB0 support?
6ES7133-0BL00-0XB0 supports PROFIBUS DP communication with transmission rates up to 12 Mbit/s.

---Which terminal blocks are compatible with the 6ES7133-0BL00-0XB0?
6ES7133-0BL00-0XB0 is compatible with TB2/DC, TB2-4/DC, TB4/DC, and TB4-4/DC terminal blocks.

---Does the 6ES7133-0BL00-0XB0 support 2-wire sensors?
6ES7133-0BL00-0XB0 supports standard 2-wire sensors with a maximum sensor leakage current of 1.5 mA.

---What is the maximum cable length supported by the 6ES7133-0BL00-0XB0?
6ES7133-0BL00-0XB0 supports unshielded cable lengths of up to 100 meters.
