Product Name:ELECTRONIC MODULE FOR ET 200S
Brand Name:Siemens
Model Number:6ES7134-4GB00-0AB0
Country of Origin:Germany
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Siemens |
Model Number: |
6ES7134-4GB00-0AB0 |
Country of Origin: |
Germany |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Specification |
|---|---|
| Model | 6ES7134-4GB00-0AB0 |
| Product Series | SIMATIC ET 200S |
| Product Type | Analog Input Module |
| Number of Inputs | 2 Analog Inputs |
| Input Signal Range | 4–20 mA |
| Resolution | 13 Bit |
| Supply Voltage | 24 V DC |
| Conversion Time | 65 ms per Channel |
| Measurement Principle | Integrating |
| Maximum Cable Length | 200 m Shielded |
| Diagnostic Functions | Wire Break, Overflow, Underflow, Group Error |
| Protection | Reverse Polarity Protection |
| Isolation Voltage | 500 V DC Tested |
| Dimensions (W × H × D) | 15 × 81 × 52 mm |
| Weight | Approx. 40 g |
| Protection Class | IP20 |
6ES7134-4GB00-0AB0 is a Siemens SIMATIC ET 200S analog input module designed for accurate acquisition of 4–20 mA process signals in industrial automation environments. Featuring two analog input channels and 13-bit resolution, the module delivers reliable measurement performance for process monitoring, instrumentation systems, and distributed control applications.
As part of the SIMATIC ET 200S I/O platform, 6ES7134-4GB00-0AB0 supports 2-wire transmitters and incorporates advanced filtering and diagnostic capabilities to enhance signal quality and operational reliability. Its compact 15 mm design helps optimize cabinet space while enabling flexible integration into decentralized automation architectures.
Widely used in manufacturing, power generation, chemical processing, and infrastructure projects, 6ES7134-4GB00-0AB0 provides dependable analog signal acquisition, improved process visibility, and efficient communication between field instrumentation and control systems.
Power Plants: Acquires transmitter signals from generators, turbines, and auxiliary systems, enabling accurate process monitoring and equipment protection.
Substations: Collects analog current signals from monitoring devices, supports SCADA integration, and improves operational visibility.
Chemical Plants: Interfaces with pressure, flow, temperature, and level transmitters, supporting precise process automation and control.
Steel Mills: Captures critical process measurements in harsh industrial environments, ensuring reliable monitoring and production efficiency.
Machinery Manufacturing Plants: Integrates analog sensors into PLC systems, supports automated production lines, and enhances machine performance monitoring.
Water Treatment Facilities: Processes measurement signals from field instruments, enabling efficient control of pumping, filtration, and distribution systems.
High-Accuracy Signal Acquisition – Supports 4–20 mA analog inputs, delivers 13-bit resolution, ensures precise process measurement.
Compact Module Design – Occupies only 15 mm installation width, saves cabinet space, simplifies system expansion.
Integrated Diagnostics – Detects wire breaks, overflow, underflow, and group faults, improving maintenance efficiency.
Advanced Signal Filtering – Supports configurable digital filtering, reduces interference effects, enhances measurement stability.
Industrial Reliability – Designed for continuous operation, provides stable signal processing, supports demanding automation environments.
Analog Signal Acquisition Function – Collects 4–20 mA process signals from field transmitters, enables accurate monitoring and control.
Data Conversion Function – Converts analog input values into digital process data, supporting PLC and automation system communication.
Diagnostic Monitoring Function – Identifies wiring faults and abnormal signal conditions, improving system reliability and troubleshooting.
Signal Conditioning Function – Applies filtering and processing to measurement signals, ensuring stable and accurate data acquisition.
Process Integration Function – Connects field instrumentation with distributed control systems, supporting efficient industrial automation.
Q1: What is the Siemens 6ES7134-4GB00-0AB0 used for?
A1: It is an ET 200S analog input module used for acquiring 4–20 mA process signals from industrial transmitters.
Q2: How many analog input channels does the module provide?
A2: The module features two analog input channels for current signal measurement.
Q3: What input signal range is supported by the 6ES7134-4GB00-0AB0?
A3: It supports standard industrial 4–20 mA current input signals.
Q4: Does the module include diagnostic functions?
A4: Yes, it provides wire-break detection, overflow monitoring, underflow monitoring, and group fault diagnostics.
Q5: Which Siemens system is compatible with the 6ES7134-4GB00-0AB0?
A5: The module is designed for integration with the SIMATIC ET 200S distributed I/O platform.
|
