Product Name: ELECTRONICS MODULE
Brand Name: Siemens
Model Number: 6ES7134-4JB51-0AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | Siemens 6ES7134-4JB51-0AB0 ELECTRONICS MODULE |
| Manufacturer | Siemens |
| Product Type | ELECTRONICS MODULE |
| Part Number | 6ES7134-4JB51-0AB0 |
| Weight | 0.05kg |
| Estimated shipping dimensions | 1.4x5.5x8.3cm |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Rated value (DC) | 24 V; From power module |
| from load voltage L+ (without load), max | 30 mA |
| from backplane bus 3.3 V DC, max. | 10 mA |
| Power loss, typ. | 0.6 W |
| Address space per module, max. | 8 byte |
| between MANA and M internally (UISO) | 75 V DC/60 V AC |
| Isolation tested with | 500 V DC |
The Siemens 6ES7134-4JB51-0AB0 is a SIMATIC DP electronic analog input module designed for the ET 200S distributed I/O system. It provides flexible RTD and resistance signal acquisition for industrial temperature monitoring applications. With support for 2 or 4-channel configurations, it enables precise measurement of RTD sensors such as Pt100, Ni100, and resistive elements used in process control and machine protection systems.
The Siemens 6ES7134-4JB51-0AB0 is engineered for high-accuracy temperature and resistance measurement in compact automation environments. Its ultra-compact 15 mm width design allows high-density installation in ET 200S systems, while integrated electrical isolation, diagnostics, and noise suppression ensure stable and reliable signal processing even in electrically noisy industrial conditions.
The primary function of the Siemens 6ES7134-4JB51-0AB0 is to convert analog resistance-based sensor signals into digital values for PLC processing. It supports both RTD temperature measurement and resistance measurement in industrial applications.
Key functions include:
Compared with conventional RTD input modules, the Siemens 6ES7134-4JB51-0AB0 offers enhanced flexibility, higher measurement stability, and improved installation efficiency in distributed automation systems.
1. Higher Installation Density
Compared with standard RTD input modules, the Siemens 6ES7134-4JB51-0AB0 offers an ultra-compact 15 mm width, enabling significantly more channels per cabinet space in ET 200S systems.
2. Greater Wiring Flexibility
Unlike many fixed-channel modules, it supports both 2-channel high-accuracy and 4-channel high-density configurations, reducing hardware variation and inventory cost.
3. Superior Noise Immunity
The integrated 50/60 Hz suppression provides more stable readings in electrically noisy environments compared to basic RTD modules without filtering.
4. Higher Diagnostic Capability
The Siemens 6ES7134-4JB51-0AB0 includes advanced diagnostics (wire break, short circuit detection), improving maintenance efficiency versus simpler analog input modules.
5. Better Measurement Stability
Digital smoothing and integrating measurement principles provide more stable outputs than low-cost RTD converters that may suffer from signal fluctuation.
6. Strong Siemens ET 200S Integration
Native compatibility with ET 200S ensures seamless configuration and reliability compared to third-party distributed I/O modules requiring additional engineering effort.
Q1: What is the main purpose of Siemens 6ES7134-4JB51-0AB0?
A: The Siemens 6ES7134-4JB51-0AB0 is used to measure RTD temperature sensors and resistance signals and convert them into digital values for PLC processing in ET 200S systems.
Q2: What types of sensors can 6ES7134-4JB51-0AB0 support?
A: The Siemens 6ES7134-4JB51-0AB0 supports Pt100, Ni100, climatic and standard RTDs, as well as resistive sensors including 150 Ω, 300 Ω, 600 Ω, and PTC types.
Q3: Can 6ES7134-4JB51-0AB0 be used in high-noise environments?
A: Yes, the Siemens 6ES7134-4JB51-0AB0 includes integrated 50/60 Hz noise suppression and electrical isolation to ensure stable measurements in industrial environments.
Q4: How many channels does 6ES7134-4JB51-0AB0 support?
A: The Siemens 6ES7134-4JB51-0AB0 supports flexible configuration of either 2 high-accuracy channels or 4 standard channels.
Q5: What industries commonly use 6ES7134-4JB51-0AB0?
A: The Siemens 6ES7134-4JB51-0AB0 is widely used in process control, HVAC systems, furnace temperature monitoring, and industrial machinery protection applications.
