Product Name: SIMATIC DP ET 200S Electronics Module
Brand Name: Siemens
Model Number: 6ES7134-4NB51-0AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Winnie |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | Siemens 6ES7134-4NB51-0AB0 SIMATIC DP ET 200S Electronics Module |
| Manufacturer | Siemens |
| Product Type | SIMATIC DP ET 200S Electronics Module |
| Part Number | 6ES7134-4NB51-0AB0 |
| Estimated shipping dimensions | 1.4x5.5x8.4cm |
| Weight | 0.04kg |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Isochronous mode | Not supported |
| Load voltage L+ rated value | 24 V DC (supplied by power module) |
| Reverse polarity protection | Yes |
| From backplane bus 3.3 V DC max | 10 mA |
| From load voltage L+ (no load) max | 30 mA |
| Typical power loss | 0.6 W |
| Address space per module max | 4 bytes |
| Number of analog inputs | 2 |
| Permissible input voltage (destruction limit) max | 9 V |
The 6ES7134-4NB51-0AB0 is a high-precision analog input module designed for RTD-based temperature measurement in industrial automation systems. It belongs to the SIMATIC ET 200S distributed I/O family and provides two RTD input channels with a compact 15 mm width, making it suitable for high-density installation in control cabinets and distributed field applications.
The module supports 15-bit plus sign high-resolution signal conversion with ±0.1% measurement accuracy, ensuring reliable and precise temperature acquisition. It is compatible with 2-wire, 3-wire, and 4-wire RTD sensors, and includes internal lead resistance compensation to maintain measurement stability across different wiring configurations and long-distance installations.
Designed for integration into Siemens ET 200S systems, the module features built-in diagnostics through an SF LED indicator for fast fault detection. Its robust industrial design and flexible sensor compatibility make it suitable for a wide range of temperature monitoring and process control applications requiring accurate and stable data acquisition.
Compact Design
The 6ES7134-4NB51-0AB0 features a slim 15 mm width, allowing high-density installation in space-constrained control systems.
High Measurement Accuracy
With ±0.1% precision and 15-bit plus sign resolution, the module ensures reliable and accurate temperature monitoring in industrial environments.
Flexible Sensor Compatibility
It supports 2-wire, 3-wire, and 4-wire RTD sensors, enabling flexible integration into various measurement setups.
Improved Signal Stability
Internal compensation for lead resistance enhances measurement stability and reduces errors in long-distance sensor wiring.
Easy Diagnostics
The integrated SF LED provides quick visual fault indication, simplifying maintenance and troubleshooting.
Seamless System Integration
As part of the ET 200S distributed I/O system, it supports flexible and scalable automation architectures.
The 6ES7134-4NB51-0AB0 delivers highly accurate and stable temperature measurement performance through its 15-bit plus sign resolution and ±0.1% measurement accuracy. It ensures precise conversion of RTD sensor signals into digital data, enabling reliable temperature monitoring in critical industrial processes.
The module enhances operational efficiency through built-in lead resistance compensation, which minimizes measurement errors caused by long cable runs or varying wiring configurations. Its ability to support multiple RTD wiring types (2-, 3-, and 4-wire) increases flexibility and reduces installation complexity, making it suitable for diverse industrial applications.
With a compact 15 mm design and low power consumption of approximately 0.6 W, the module supports high-density installation while maintaining energy-efficient operation. Integration into the ET 200S distributed system further improves system scalability and reduces overall wiring and maintenance costs.
1. How is fault diagnosis handled in the 6ES7134-4NB51-0AB0?
The 6ES7134-4NB51-0AB0 includes an SF LED indicator that displays module fault status for quick troubleshooting.
2. How many input channels does the 6ES7134-4NB51-0AB0 support?
The 6ES7134-4NB51-0AB0 supports 2 analog RTD input channels.
3. What types of RTD sensors are compatible with the 6ES7134-4NB51-0AB0?
The 6ES7134-4NB51-0AB0 supports 2-wire, 3-wire, and 4-wire RTD sensor configurations.
4. What is the accuracy of the 6ES7134-4NB51-0AB0?
The 6ES7134-4NB51-0AB0 provides ±0.1% measurement accuracy with 15-bit plus sign resolution.
5. How does the 6ES7134-4NB51-0AB0 improve measurement stability?
The 6ES7134-4NB51-0AB0 includes internal lead resistance compensation to reduce measurement errors and improve stability.
6. What is the size of the 6ES7134-4NB51-0AB0 module?
The 6ES7134-4NB51-0AB0 has a compact width of 15 mm for space-saving installation.
