Product Name:3300 XL 8 mm Proximity Probes
Brand Name:Bently Nevada
Model Number:330104-00-05-50-02-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330104-00-05-50-02-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Description |
|
Model |
330104-00-05-50-02-00 |
|
Series |
3300 XL 8 mm Proximity Probe |
|
Thread Type |
M10 x 1 |
|
Total Cable Length |
5.0 m |
|
Connector Type |
Miniature ClickLoc coaxial |
|
Cable Type |
Standard triaxial industrial cable |
|
Output Signal |
Eddy current proximity signal |
|
Operating Principle |
Non-contact displacement measurement |
|
Probe Material |
Stainless steel body construction |
|
Cable Resistance |
Approx. 8.7 Ω (typical for 5 m probe) |
|
Weight |
0.56kg |
|
Dimension |
24x24x3cm |
The 330104-00-05-50-02-00 is part of the Bently Nevada 3300 XL 8 mm proximity probe series, designed for precise non-contact vibration and position monitoring in rotating machinery. It provides highly stable eddy-current measurement performance for industrial asset protection and condition monitoring systems.
The 330104-00-05-50-02-00 probe works as a key element of the 3300 XL transducer system, supporting accurate shaft displacement and vibration tracking in turbines, compressors, and motors. Its robust construction ensures reliable operation in high-temperature and electrically noisy environments.
Compatible with the 3300 XL 8 mm probe family, including 330103 and other reverse-mount configurations, this model offers flexible integration with standard Proximitor sensors and extension cables, ensuring full system interchangeability and simplified maintenance in critical applications.
Q1: What is the 330104-00-05-50-02-00 used for?
A1: It is used for non-contact vibration and position measurement in rotating machinery such as turbines and compressors.
Q2: Is the 330104-00-05-50-02-00 compatible with other 3300 XL systems?
A2: Yes, it is fully compatible with 3300 XL Proximitor Sensors and extension cables.
Q3: What is the cable length of this probe model?
A3: This configuration provides a 5.0-meter total cable length.
Q4: Can it operate in harsh industrial environments?
A4: Yes, it is designed for high temperature, vibration, and EMI-heavy industrial conditions.
Q5: Does it support ClickLoc connectors?
A5: Yes, it uses a miniature ClickLoc coaxial connector for secure and fast installation.
| Number | Describe |
|---|---|
| 148722-01 | 3300 XL test plug with 3-pin test adapter, color-coded 1 m wires and banana plugs for Proximitor sensor field testing without wiring removal |
| 04310310 | 3300 XL Proximitor sensor panel-mount screw, 6-32 UNC thread forming screw, 4 pcs required per sensor assembly |
| 03200006 | Silicone self-fusing tape, 9.1 m roll, provides electrical insulation and environmental sealing for connector protection |
| 40113-02 | Connector protector kit for 3300 XL 8 mm probes and extension cables, includes protectors and installation tools |
| 136536-01 | Connector protector adapter for compatibility with pre-1998 installation tools used with 75Ω ClickLoc connectors |
| 40180-02 | Connector protectors set, includes 10 pairs for 3300 XL probe and extension cable environmental sealing |
| 03839410 | 75Ω triaxial male connector protector for extension cable side, ensures sealed connection with vibration monitoring systems |
| 03839420 | 75Ω triaxial female connector protector for probe side or Proximitor connection protection in harsh environments |
| 04301007 | 3/8-24 probe lock nut with safety wire holes for secure mechanical fixation of proximity probes |
| 04301008 | M10 x 1 probe lock nut with safety wire holes for vibration probe installation locking and safety wiring |
| 330153-01 | 3300 XL connector kit with ClickLoc connectors, sleeves, tubing and silicone tape for standard probe and cable assembly |
| 330153-09 | ETR connector kit for high-temperature 3300 XL systems, includes high-temp connectors and insulation components |
| 163356 | Connector crimp tool kit with inserts and installation guide for ClickLoc connector assembly and maintenance |
