Product Name: SIMATIC DP ET 200iSP Analog Input Electronic Submodule
Brand Name: Siemens
Model Number: 6ES7134-7TD50-0AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales: |
Email: |
Whatsapp: |
Jim Pei |
| Product Name | Siemens 6ES7134-7TD50-0AB0 SIMATIC DP ET 200iSP Analog Input Electronic Submodule |
| Manufacturer | Siemens |
| Product Type | SIMATIC DP ET 200iSP Analog Input Electronic Submodule |
| Part Number | 6ES7134-7TD50-0AB0 |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Module Type | 4 AI HART, 4DMU |
| Number of Analog Inputs | 4 |
| Input Signal Range | 4–20 mA |
| Input Resistance | 295 Ω |
| Maximum Input Current (Destruction Limit) | 50 mA |
| Supply Current (L+) | Max. 30 mA |
| Typical Power Loss | 0.4 W |
| Measurement Principle | Sigma-Delta Integrating |
| Cycle Time (All Channels) | Max. 120 ms |
| Basic Conversion Time | 30 ms per Channel |
| Resolution | 12-bit + Sign |
| Interference Suppression Frequency | 50/60 Hz |
| Maximum Shielded Cable Length | 500 m |
| Supported Encoder/Transducer | 4-Wire Current Transducer |
| Linearity Error | ±0.015% |
| Temperature Error | ±0.005%/K |
| Repeat Accuracy (25°C) | ±0.01% |
| Operational Error | ±0.15% |
| Basic Error (25°C) | ±0.1% |
| Crosstalk Between Inputs | Min. -50 dB |
| Series Mode Interference Rejection | Min. 70 dB |
| Hazardous Area Certification | II2 G (1) GD Ex ib[ia] IIC T4, I M2 Ex ib[ia] I |
| ATEX Certification | KEMA 04 ATEX 1245 |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The Siemens 6ES7134-7TD50-0AB0 SIMATIC DP ET 200iSP Analog Input Electronic Submodule is a 4-channel HART analog input module designed for the ET 200iSP distributed I/O system. It supports 4–20 mA input signals from 4-wire transmitters and delivers accurate signal acquisition with Sigma-Delta conversion technology. Certified for hazardous areas, the module combines high measurement precision, HART communication capability, and reliable industrial performance for demanding process automation applications.
Compared with similar hazardous-area analog input modules, the Siemens 6ES7134-7TD50-0AB0 provides higher measurement accuracy, HART communication support, and dependable operation in process industries.
Q1: What is the 6ES7134-7TD50-0AB0 used for?
A1: 6ES7134-7TD50-0AB0 is used for acquiring 4–20 mA analog signals from field transmitters in process automation systems.
Q2: How many analog input channels does the 6ES7134-7TD50-0AB0 provide?
A2: 6ES7134-7TD50-0AB0 provides 4 analog input channels.
Q3: Does the 6ES7134-7TD50-0AB0 support HART communication?
A3: 6ES7134-7TD50-0AB0 supports HART communication for compatible field instruments.
Q4: What input signal range is supported by the 6ES7134-7TD50-0AB0?
A4: 6ES7134-7TD50-0AB0 supports standard 4–20 mA current input signals.
Q5: What measurement technology does the 6ES7134-7TD50-0AB0 use?
A5: 6ES7134-7TD50-0AB0 uses Sigma-Delta integrating conversion for accurate analog measurements.
Q6: Can the 6ES7134-7TD50-0AB0 be used in hazardous areas?
A6: 6ES7134-7TD50-0AB0 is certified for hazardous environments with ATEX and Ex approvals.
