Product Name:ELECTRONIC MODULE FOR ET 200S
Brand Name:Siemens
Model Number:6ES7135-4GB01-0AB0
Country of Origin:Germany
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Siemens |
Model Number: |
6ES7135-4GB01-0AB0 |
Country of Origin: |
Germany |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Value |
|---|---|
| Product Model | 6ES7135-4GB01-0AB0 |
| Product Type | Analog Output Module |
| System | SIMATIC ET 200S |
| Output Channels | 2 AO |
| Output Signal Range | 0–20 mA / 4–20 mA / ±20 mA |
| Resolution | 13-bit (14-bit with sign) |
| Cycle Time | < 1.5 ms |
| Load Impedance | Max. 500 Ω |
| Supply Voltage | 24 V DC (via power module) |
| Backplane Current | Max. 10 mA |
| Power Loss | Max. 2 W |
| Cable Length | Up to 200 m (shielded) |
| Diagnostics | Wire-break, group fault (SF LED) |
| Output Type | Current output (2-wire supported) |
| Dimensions (W × H × D) | 15 × 81 × 52 mm |
| Weight | 0.04 kg |
| Isolation | Channel to backplane bus, load voltage separated |
The 6ES7135-4GB01-0AB0 is a Siemens SIMATIC ET 200S analog output electronic module designed for precise current signal control in distributed automation systems. It provides 2-channel analog outputs supporting both 0–20 mA and 4–20 mA ranges, with high-resolution 13-bit performance for stable and accurate process actuation.
The 6ES7135-4GB01-0AB0 supports fast cycle times below 1.5 ms, ensuring responsive signal updates for demanding industrial control applications. Its compact 15 mm housing allows efficient space utilization in ET 200S modular I/O configurations.
Engineered for reliability, the 6ES7135-4GB01-0AB0 offers strong diagnostic capabilities including wire-break detection and group fault indication, making it suitable for precision control in modern industrial automation environments.
Q1: What is the main function of 6ES7135-4GB01-0AB0?
A1: It provides analog current output control for ET 200S automation systems.
Q2: How many output channels does it have?
A2: It features 2 analog output channels.
Q3: What output ranges are supported?
A3: It supports 0–20 mA, 4–20 mA, and ±20 mA outputs.
Q4: Is it suitable for fast control applications?
A4: Yes, it has a cycle time of less than 1.5 ms for fast response.
Q5: Does it support fault diagnostics?
A5: Yes, it includes wire-break detection and group fault indication via SF LED.
|
