Bently Nevada 146031-02 100Base-FX (Fiber Optic) I/O Module Original new, China Bently Nevada 146031-02 100Base-FX (Fiber Optic) I/O Module Original new Manufacturers, Suppliers, Factory

Overview

Brand Name:	Bently Nevada
Model Number:	146031-02
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	146031-02
Brand	Bently Nevada
Product Series	3500/22M Transient Data Interface Module
Power Consumption	10.5 Watts
Ethernet Communication	10Base-T / 100Base-TX
Fiber Optic Communication	100Base-FX
USB Interface	Front Panel USB-B
Protocol Support	BN Host Protocol / BN TDI Protocol
Operating Temperature	-30°C to +65°C
Storage Temperature	-40°C to +85°C
Humidity Rating	95% non-condensing
Module Dimensions	2.4x11x33cm
I/O Module Dimensions	241.3 × 24.4 × 99.1 mm
Module Weight	0.42kg
I/O Module Weight	0.20 kg
Rack Requirement	1 Full-height Front Slot
Communication Connector	RJ-45 / MT-RJ Fiber Connector

Description

Bently Nevada146031-02is a reliable industrial monitoring component designed for use with the advanced3500/22M Transient Data Interface Moduleplatform. Engineered for high-speed data communication and machinery condition monitoring, this module supports continuous acquisition of steady-state and transient waveform information in critical rotating equipment applications.

The146031-02module enables efficient integration between the3500 Seriesmonitoring rack and diagnostic software systems, including condition monitoring and machinery protection platforms. With Ethernet communication capability, dynamic waveform collection, and stable rack interface performance, it helps improve predictive maintenance efficiency and overall operational reliability in industrial environments.

As part of the trustedBently Nevada3500/22Mfamily, models such as146031-01and146031-02are widely used in turbines, compressors, generators, and process control systems where accurate machinery diagnostics and real-time monitoring are essential.

Applications

Power plants:Used for turbine generator monitoring, vibration analysis, and machinery protection systems.
Substations:Supports communication and condition monitoring of auxiliary rotating equipment.
Chemical plants:Integrates machinery diagnostics with process automation and safety monitoring systems.
Steel mills:Performs stable monitoring in environments with high temperatures and electromagnetic interference.
Machinery manufacturing plants:Applied in automated production systems and industrial equipment diagnostics.
Oil & gas facilities:Used for compressor, pump, and turbine condition monitoring applications.
Marine industry:Supports propulsion machinery and onboard equipment monitoring systems.

Features

High-speed transient data acquisition capability
Supports dynamic waveform and static value collection
Integrated Ethernet communication interface
Compatible with System 1 condition monitoring software
Advanced rack communication and diagnostic functions
Supports synchronous and asynchronous waveform sampling
Reliable operation in industrial environments
Compact modular design for 3500 rack systems

Functions

Transfers monitoring data between rack and host systems
Collects steady-state and transient machinery data
Supports predictive maintenance and fault diagnostics
Enables real-time vibration and condition monitoring
Provides communication interface for 3500 monitoring systems
Assists machinery protection and operational analysis
Improves industrial equipment reliability and uptime

FAQ

Q1:What is the main function of the146031-02module?
A1:It is used for transient data acquisition and communication within the 3500 monitoring system.

Q2:Which communication protocols are supported by the146031-02?
A2:It supports BN Host Protocol and BN TDI Protocol through Ethernet communication.

Q3:Can the146031-02collect waveform data?
A3:Yes, it supports both synchronous and asynchronous waveform sampling for machinery analysis.

Q4:What industries commonly use the146031-02module?
A4:It is widely used in power generation, oil & gas, chemical, marine, and heavy industrial sectors.

Q5:Is the146031-02compatible with the 3500 monitoring rack?
A5:Yes, it is specifically designed for integration with theBently Nevada3500 Series monitoring system.

Spares

Number	Description
288055-01	Standard Transient Data Interface Module supplied with USB cable for 3500 monitoring system applications.
123M4610	10-foot USB A to B communication cable for module connection and configuration.
146031-01	10Base-T/100Base-TX I/O module for Ethernet communication in 3500/22M systems.
146031-02	100Base-FX fiber optic I/O module designed for high-speed optical Ethernet communication.
161580	3500/22M TDI operation and maintenance user guide for installation and technical reference.
164466	Network accessories datasheet for 3500 communication and connectivity components.
00580441	3-position green internal termination connector header for module wiring applications.
00580436	6-position green internal termination connector header for industrial signal connections.
111M5777	2-position green internal termination connector header for system wiring interfaces.
166M2390	Push-in spring type connector header, alternative replacement for part number 00580436.
166M4363	Push-in spring type connector header, alternative replacement for part number 00580441.
146031-03	10Base-T/100Base-TX I/O module with gold-plated contacts for enhanced connection reliability.
