Product Name: Electronics Module
Brand Name: Siemens
Model Number: 6ES7138-4DA04-0AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | Siemens 6ES7138-4DA04-0AB0 Electronics Module |
| Manufacturer | Siemens |
| Product Type | Electronics Module |
| Part Number | 6ES7138-4DA04-0AB0 |
| Weight | 0.05kg |
| Estimated shipping dimensions | 1.4x5.5x8.3cm |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Rated value (DC) | 24 V |
| permissible range, lower limit (DC) | 20.4 V |
| permissible range, upper limit (DC) | 28.8 V |
| from load voltage L+ (without load), max. | 42 m |
| for signal | -30 to +5 V |
| for signal | +11 to +30V |
| Number of Channels | 1 |
| Input Voltage | 24 V |
| Maximum Counting Frequency | 100 kHz |
| Mounting Width | 15 mm |
The Siemens 6ES7138-4DA04-0AB0 is a SIMATIC DP electronics module designed for the ET 200S distributed I/O system, providing high-speed pulse counting and measurement functionality for demanding industrial automation applications. Featuring a single high-speed counting channel, the module accurately processes 24 V pulse signals with frequencies up to 100 kHz, making it ideal for encoder feedback, position monitoring, speed measurement, and production tracking systems.
The Siemens 6ES7138-4DA04-0AB0 is engineered for applications requiring precise pulse acquisition and synchronization. Its compact 15 mm form factor allows space-saving installation in ET 200S stations, while advanced functions such as isochronous mode, cycle duration measurement, gate control, and latch capabilities help deliver accurate and reliable performance in motion control, packaging, material handling, and high-speed manufacturing environments.
The primary function of the Siemens 6ES7138-4DA04-0AB0 is to acquire, count, and process high-speed pulse signals from industrial sensors and encoders.
Key functions include:
Compared with conventional counter modules, the Siemens 6ES7138-4DA04-0AB0 provides faster signal processing, improved synchronization accuracy, and seamless integration into ET 200S automation systems.
1. High-Speed Counting Performance
The Siemens 6ES7138-4DA04-0AB0 supports pulse frequencies up to 100 kHz, allowing accurate monitoring of fast-moving equipment and high-speed production processes.
2. Advanced Timing and Synchronization
Unlike basic counter modules, the Siemens 6ES7138-4DA04-0AB0 supports isochronous operation and clock synchronization for highly accurate measurement applications.
3. Compact Installation Design
With a mounting width of only 15 mm, the Siemens 6ES7138-4DA04-0AB0 enables high channel density and efficient cabinet space utilization.
4. Enhanced Measurement Accuracy
High-resolution cycle duration measurement provides more precise process monitoring than standard pulse counting modules.
5. Integrated Diagnostic Functions
The Siemens 6ES7138-4DA04-0AB0 includes diagnostic capabilities that simplify troubleshooting and reduce system downtime.
6. Native ET 200S Compatibility
Designed specifically for ET 200S systems, the Siemens 6ES7138-4DA04-0AB0 offers easier engineering and better operational reliability than third-party alternatives.
Q1: What is the maximum counting frequency of 6ES7138-4DA04-0AB0?
A: The Siemens 6ES7138-4DA04-0AB0 supports pulse counting frequencies up to 100 kHz.
Q2: Can 6ES7138-4DA04-0AB0 be used with rotary encoders?
A: Yes, the Siemens 6ES7138-4DA04-0AB0 is suitable for connecting rotary encoders, linear encoders, proximity sensors, and other pulse-output devices.
Q3: Does 6ES7138-4DA04-0AB0 support synchronized measurement applications?
A: Yes, the Siemens 6ES7138-4DA04-0AB0 supports isochronous mode and clock synchronization for precise timing and motion control applications.
Q4: What automation systems are compatible with 6ES7138-4DA04-0AB0?
A: The Siemens 6ES7138-4DA04-0AB0 is specifically designed for integration into Siemens SIMATIC ET 200S distributed I/O systems.
Q5: What industries commonly use 6ES7138-4DA04-0AB0?
A: The Siemens 6ES7138-4DA04-0AB0 is widely used in packaging machinery, conveyor systems, material handling equipment, motion control applications, and high-speed manufacturing processes.
