Siemens 6ES7138-6BA01-0BA0 is the SIMATIC ET 200SP TM PosInput 1 counter and position decoder module. The official description identifies support for RS-422 incremental encoders or SSI absolute encoders, two digital inputs, two digital outputs and BaseUnit type A0.
Brand |
Siemens |
Series |
SIMATIC ET 200SP |
Article number |
6ES7138-6BA01-0BA0 |
Official description |
TM PosInput 1 counter and position decoder module for RS-422 incremental encoders or SSI absolute encoders, with 2 DI and 2 DQ, suitable for BaseUnit type A0 |
|
Article number
|
6ES7138-6BA01-0BA0
|
|
Product designation
|
TM PosInput 1
|
|
Encoder connection
|
RS-422 incremental encoder or SSI absolute encoder
|
|
Digital inputs
|
2 DI
|
|
Digital outputs
|
2 DQ
|
|
BaseUnit suitability
|
Type A0
|
|
Packing quantity
|
1 unit
|
|
Module format
|
SIMATIC ET 200SP technology module
|
|
Signal interface
|
Encoder, 2 DI and 2 DQ connections
|
|
BaseUnit
|
Separate BaseUnit type A0 required
|
|
Station integration
|
ET 200SP configuration subject to verification
|
|
