Product Name: SIMATIC DP ET 200PRO 16 DI 24 V DC Electronic Module
Brand Name: Siemens
Model Number: 6ES7141-4BH00-0AA0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
| Product Name | Siemens 6ES7141-4BH00-0AA0 SIMATIC DP ET 200PRO 16 DI 24 V DC Electronic Module |
| Manufacturer | Siemens |
| Product Type | SIMATIC DP ET 200PRO 16 DI 24 V DC Electronic Module |
| Part Number | 6ES7141-4BH00-0AA0 |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Number of Digital Inputs | 16 |
| Input Voltage | 24 V DC |
| Module Diagnostics | Yes |
| Bus Module | Included |
| Rated Supply Voltage | 24 V DC |
| Reverse Polarity Protection | Yes, against destruction |
| Maximum Current from Supply Voltage 1L+ | 30 mA |
| Backplane Bus Current | Max. 20 mA @ 3.3 V DC |
| Number of Encoder Supply Outputs | 8 |
| Encoder Supply Short-Circuit Protection | Yes, electronic, per module |
| Maximum Encoder Supply Output Current | 1 A up to 55°C |
| Typical Power Loss | 3 W |
| Maximum Address Space | 2 Bytes |
| Simultaneously Controllable Inputs | Max. 16 up to 55°C |
| Rated Input Voltage | 24 V DC |
| Input Voltage for Signal "0" | -3 to +5 V |
| Input Voltage for Signal "1" | +11 to +30 V |
| Typical Input Current for Signal "1" | 4 mA |
| Input Delay, "0" → "1" | 1.2–4.8 ms |
| Input Delay, "1" → "0" | 0.7–3 ms |
| Maximum Unshielded Cable Length | 30 m |
| 2-Wire Sensor Support | Yes |
| Maximum Quiescent Current for 2-Wire Sensor | 1.5 mA |
| Diagnostic Function | Yes |
| Diagnostic Alarm | Yes |
| Diagnostic Information | Readable |
| Short-Circuit Diagnostics | Yes; sensor supply to M, module by module |
| Group Error Indicator | SF, Red LED |
| Digital Input Status Indicator | Green LED, per channel |
| Backplane Bus Isolation | Yes, isolated from all other circuit components |
| Channel-to-Channel Isolation | No |
| Digital Inputs to Backplane Bus Isolation | Yes |
| Isolation Test Voltage | 707 V DC (Type Test) |
|
Sales |
|
Phone/Whatsapp |
|
Jim Pei |
The Siemens 6ES7141-4BH00-0AA0 SIMATIC DP ET 200PRO Electronic Module is a 16-channel 24 VDC digital input module designed for the SIMATIC ET 200PRO distributed I/O platform. It provides reliable acquisition of digital signals from sensors, switches, and other field devices while supporting 2-wire sensors and providing eight encoder supply outputs. Integrated module diagnostics, diagnostic alarms, electronic short-circuit protection for the sensor supply, individual channel status LEDs, and reverse polarity protection simplify system monitoring and troubleshooting. With electrical isolation between the digital inputs and backplane bus, the module provides dependable field signal acquisition for decentralized industrial automation systems.
The Siemens 6ES7141-4BH00-0AA0 is designed for collecting 24 VDC digital signals from industrial field devices such as proximity sensors, limit switches, photoelectric sensors, push buttons, selector switches, and machine status contacts. Its 16 digital inputs and support for 2-wire sensors make it suitable for monitoring machine positions, product presence, equipment status, safety-related auxiliary signals, and production sequences in automated machinery.
As part of the SIMATIC ET 200PRO platform, the module is well suited for distributed I/O applications in automotive manufacturing, assembly lines, packaging machinery, conveyor systems, material handling equipment, logistics automation, and general factory production. Its integrated diagnostics, sensor supply protection, and individual input status indication help simplify commissioning and maintenance while supporting reliable operation close to machines and production processes.
