Bently Nevada 330106-05-30-15-02-CN 3300 XL 8 mm Reverse Mount Probes In stock, China Bently Nevada 330106-05-30-15-02-CN 3300 XL 8 mm Reverse Mount Probes In stock Manufacturers, Suppliers, Factory

Overview

Brand Name:	Bently Nevada
Model Number:	330106-05-30-15-02-CN
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Model Number	330106-05-30-15-02-CN
Product Type	3300 XL 8 mm Reverse Mount Proximity Probe
Thread Type	M10 x 1
Probe Configuration	Reverse Mount
Total Cable Length	1.5 meters (4.9 ft)
Connector Type	Miniature ClickLoc coaxial connector
Cable Type	Standard cable
Measurement Technology	Eddy Current Proximity Sensing
Linear Range	2 mm (80 mils)
Frequency Response	0 to 10 kHz
Recommended Gap Setting	-9 Vdc (1.27 mm / 50 mils)
Probe Tip Material	Polyphenylene Sulfide (PPS)
Probe Case Material	AISI 303/304 Stainless Steel
Connector Material	Gold-plated brass / beryllium copper
Tensile Strength	330 N (75 lbf)
Operating Temperature	-52°C to +177°C
Extended Cable Temperature	Up to +260°C (ETR option)
System Length Compatibility	5 m or 9 m systems
Minimum Shaft Diameter	50.8 mm (2 in)
Recommended Shaft Diameter	76.2 mm (3 in)
Weight	Approx. 323 g/m probe cable
Compliance	API 670, CE, RoHS, SIL 2
Hazardous Area Approval	CSA, ATEX, IECEx

Description

Bently Nevada330106-05-30-15-02-CNreverse mount proximity probe is designed for high-precision shaft vibration and position monitoring in rotating machinery. As part of the3300 XL 8 mmtransducer series, it delivers stable eddy current sensing performance for turbines, compressors, pumps, and other critical industrial assets. The reverse mount configuration withM10 x 1 threadsprovides reliable installation in restricted mechanical spaces.

Built with corrosion-resistant stainless steel construction and gold-plated ClickLoc connectors,330106-05-30-15-02-CNoffers dependable signal transmission and strong resistance to vibration, oil contamination, and electromagnetic interference. The 1.5-meter cable length and robust probe structure help improve long-term operational reliability in demanding industrial environments.

Compatible with3300 XL Proximitor Sensors, extension cables, and selected non-XL 3300 systems,330106-05-30-15-02-CNsupports API 670 compliant machinery protection applications. Its rugged design, accurate linear response, and easy integration make it suitable for continuous condition monitoring and predictive maintenance systems across power generation, oil & gas, petrochemical, and manufacturing industries.

Applications

Power plants:Used for steam turbine vibration monitoring, shaft displacement measurement, and generator protection systems.
Oil & gas facilities:Applied in compressors, pumps, and rotating equipment condition monitoring under harsh operating conditions.
Petrochemical plants:Supports continuous machinery diagnostics and predictive maintenance systems.
Steel mills:Performs reliable vibration detection in high-temperature and heavy electromagnetic environments.
Industrial manufacturing:Integrated into automated production equipment, high-speed motors, and precision rotating machinery.
Marine industry:Used for propulsion equipment monitoring and offshore platform rotating asset protection.
Paper and cement industries:Provides stable shaft vibration feedback for critical process equipment.

Features

Reverse mount probe design for compact installation areas
High-accuracy eddy current sensing technology
Compatible with 3300 XL Proximitor sensors
Rugged stainless steel probe construction
Gold-plated ClickLoc connectors for secure connection
Excellent resistance to oil, vibration, and EMI/RFI
Supports API 670 compliant machinery monitoring
Wide operating temperature capability
Optional FluidLoc cable configuration available
Suitable for hazardous industrial environments

Functions

Measures shaft vibration in rotating machinery
Monitors axial position and radial displacement
Supports machine protection and alarm systems
Provides real-time condition monitoring signals
Enables predictive maintenance strategies
Assists overspeed and Keyphasor reference measurements
Improves equipment reliability and operational safety
Reduces unplanned downtime and maintenance costs

FAQ

Q1:What is the main function of the330106-05-30-15-02-CNprobe?
A1:It is used for non-contact vibration and shaft position monitoring in rotating industrial machinery.

Q2:Is330106-05-30-15-02-CNcompatible with API 670 systems?
A2:Yes, the 3300 XL 8 mm system is designed to support API 670 compliant applications.

Q3:What connector type does this probe use?
A3:It uses a miniature ClickLoc coaxial connector with secure locking functionality.

Q4:Can this probe operate in high-temperature environments?
A4:Yes, standard operation supports up to +177°C, with extended temperature options available.

Q5:Which industries commonly use the330106-05-30-15-02-CNprobe?
A5:It is widely used in power generation, oil & gas, petrochemical, steel, marine, and manufacturing industries.

Spares

Number	Description
148722-01	3300 XL test plug with 3 color-coded test pins and 1-meter banana plug wires for Proximitor sensor signal verification without removing field wiring.
04310310	6-32 UNC panel-mount forming screw for 3300 XL Proximitor Sensor; four screws required per sensor installation.
03200006	Silicone self-fusing tape roll (9.1 m) for connector insulation and environmental protection; not recommended for internal machine use.
40113-02	Connector Protector Kit for 3300 XL 8 mm probes and extension cables including protectors and installation tools.
136536-01	Connector protector adapter enabling compatibility with pre-1998 installation tools for 75Ω ClickLoc connectors.
40180-02	Connector protectors package containing 10 pairs for 3300 XL 8 mm probes and extension cable environmental sealing.
03839410	75Ω triaxial male connector protector for extension cable side, ensuring environmental protection of signal connections.
03839420	75Ω triaxial female connector protector for probe lead and Proximitor connection protection against contamination and moisture.
04301007	3/8-24 probe lock nut with safety wire holes for secure mechanical fixation of probe installation.
04301008	M10 x 1 probe lock nut with safety wire holes designed for secure probe mounting in industrial environments.
330153-01	3300 XL connector kit including male/female ClickLoc connectors, sleeves, tubing, and sealing tape for probe system assembly.
