Siemens 6ES7141-6BH00-0AB0 PROFINET Distributed I/O Module

Siemens 6ES7141-6BH00-0AB0 PROFINET Distributed I/O Module

Product Name: PROFINET Distributed I/O Module

Brand Name: Siemens

Model Number: 6ES7141-6BH00-0AB0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

Overview
Contact Us
Specifications
Description
Functions
Advantage
Why Choose US
Other Products
Recommended Products

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Contact Us

Sales:	Email:	Whatsapp:
*Jim Pei*	*[email protected]*	*+86 18020776782*

Specifications

Product Name	Siemens 6ES7141-6BH00-0AB0 PROFINET Distributed I/O Module
Manufacturer	Siemens
Product Type	PROFINET Distributed I/O Module
Part Number	6ES7141-6BH00-0AB0
Place of shipment	Xiamen, China
Country of origin	Germany
Supply Voltage	24 V DC
Permissible Supply Range	20.4 ~ 28.8 V DC
Reverse Connection Protection	Supported
Typical Current Consumption	100 mA
Typical Power Consumption	6.5 W
Number of Digital Input Points	16 points
Rated Input Voltage	24 V DC
Signal "0" Voltage Range	-3 ~ +5 V
Signal "1" Voltage Range	11 ~ 30 V
Input Current (Signal 1)	Typical 7 mA
Quiet Leakage Current (Signal 0)	Maximum 1.5 mA
Input Response Time	0→1: Approx. 3 ms; 1→0: Approx. 3 ms
Number of Encoder Powered Outputs	8 channels
Encoder Supply Voltage	24 V DC
Encoder Supply Current	100 mA/channel
Communication Interface	2 × PROFINET (100BASE-TX)
Maximum Communication Rate	100 Mbit/s
Permissible Potential Difference Between Different Circuits	75 V DC / 60 V AC
Isolation Voltage (24V Loop)	500 V
Network Interface Isolation	1500 V (compliant with IEEE 802.3)

Description

The Siemens 6ES7141-6BH00-0AB0 is a PROFINET distributed I/O module designed to collect digital input signals and transmit them to a PLC over a PROFINET network. It features 16 digital input channels with a 24 VDC rated input voltage, making it suitable for connecting sensors, switches, and other field devices in distributed automation systems. Equipped with dual PROFINET interfaces, integrated encoder power outputs, and electrical isolation, the module enables reliable signal acquisition and network communication while simplifying field-level wiring and system expansion in industrial automation applications.

Functions

Acquires 16 digital input signals from field devices.

Transmits input data to the PLC through a PROFINET network.

Provides 24 VDC power to connected encoders through eight dedicated supply channels.

Supports distributed I/O architecture for decentralized automation systems.

Enables fast signal acquisition with approximately 3 ms input response time.

Provides electrical isolation to improve communication reliability and system protection.

Advantage

Compared with conventional remote I/O modules, the Siemens 6ES7141-6BH00-0AB0 offers high-speed PROFINET communication, integrated encoder power supply, and reliable industrial performance. Its distributed design helps reduce wiring complexity while improving system flexibility and scalability.

Dual PROFINET Interfaces: Supports two 100BASE-TX PROFINET ports for flexible network integration and simplified distributed system architecture.
Integrated Encoder Power Supply: Provides eight 24 VDC encoder supply outputs with up to 100 mA per channel, reducing the need for external power distribution.
Fast Signal Response: Offers approximately 3 ms input response time for accurate and timely acquisition of field signals.
Reliable Electrical Isolation: Features 500 V circuit isolation and 1500 V network isolation, improving protection against electrical interference.
Wide Industrial Voltage Compatibility: Operates within a 20.4–28.8 VDC supply range and includes reverse polarity protection for reliable installation.
Reduced Wiring Requirements: Distributed I/O architecture minimizes field wiring and simplifies machine expansion and maintenance.
Optimized for PROFINET Automation: Designed for seamless integration into Siemens PROFINET-based automation systems, supporting efficient communication and centralized control.

Why Choose US

✔ Genuine Industrial Automation Products
✔ Strict Quality Inspection Before Shipment
✔ Competitive Prices & Flexible Quotations
✔ Large Inventory with Fast Global Shipping
✔ 12-Month Warranty on Eligible Products
✔ Professional Technical & After-Sales Support
✔ Inquiry Response Within 1 Hour
✔ Secure Packaging for International Shipping
✔ Trusted Supplier for PLC, DCS, HMI, and Industrial Control Systems
