Honeywell 8C-PAIN01 51454356-175 Analog Input Module In stock

Honeywell 8C-PAIN01 51454356-175 Analog Input Module In stock

Product Name:Analog Input Module

Brand Name:Honeywell

Model Number:8C-PAIN01 51454356-175

Country of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

honeywell 8c pain01 51454356 175 analog input module in stock-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Honeywell
Model Number:	8C-PAIN01 51454356-175
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Model Number	8C-PAIN01 51454356-175
Product Type	Analog Input Module
Input Channels	16 Single-Ended Channels
Input Signal Range	4–20 mA
Input Type	2-wire or self-powered transmitters
A/D Resolution	16-bit
Input Scan Rate	50 ms
Hardware Accuracy	±0.075% Full Scale
Maximum Input Voltage	±30 V
Power Supply	24 VDC
Module Current Rating	105 mA
Normal Mode Rejection	19 dB at 60 Hz
Crosstalk	-60 dB
Compatible IOTA	8C-TAIX51 / 8C-TAIX61
Dimension	6x15.5x14.3cm
Weight	0.3kg
Mounting Style	Vertical Cabinet Mounting
Protection Feature	Conformal Coated Electronics

Description

8C-PAIN01 51454356-175 is a high-performance analog input module developed for Honeywell PlantCruise and Experion Series 8 control systems. Designed for reliable 4–20 mA signal acquisition, this module supports up to 16 single-ended analog input channels and delivers stable process monitoring in demanding industrial environments. Its conformal-coated construction improves resistance to moisture, dust, and temperature fluctuations, making it suitable for harsh plant conditions.

The 8C-PAIN01 works seamlessly with 8C-TAIX51 non-redundant and 8C-TAIX61 redundant IOTA assemblies, providing flexible installation options for process automation projects. Compared with conventional analog input hardware, the module offers faster loop scanning, compact cabinet integration, and simplified field wiring maintenance.

With advanced self-diagnostics, non-incendive field power capability, and high measurement accuracy, 8C-PAIN01 51454356-175 is widely used in power generation, petrochemical processing, manufacturing automation, and distributed control systems requiring dependable analog signal transmission and long-term operational stability.

Applications

Power plants: Used for turbine monitoring systems, analog signal acquisition, and process instrumentation integration.
Substations: Support monitoring of auxiliary systems, signal conditioning, and industrial automation control.
Chemical plants: Enable stable process signal collection in corrosive and hazardous operating environments.
Steel mills: Provide reliable analog measurement performance under strong electromagnetic interference conditions.
Machinery manufacturing plants: Applied in automated production lines, packaging systems, and robotic control platforms.
Oil & gas facilities: Used for transmitter signal monitoring and distributed control system integration.
Water treatment plants: Support process automation and centralized instrumentation management.

Features

Supports 16-channel analog input acquisition
Compatible with 4–20 mA transmitters
High-speed 50 ms scan performance
Integrated self-diagnostic capability
Optional redundant IOTA configuration
Compact Series 8 cabinet design
Conformal coating for harsh environments
Non-incendive field power support
Simplified wiring and maintenance structure

Functions

Receives high-level 4–20 mA analog signals from industrial transmitters and field sensing devices.
Converts analog process data into digital signals for Honeywell control and monitoring systems.
Supports accurate real-time signal acquisition for distributed control system (DCS) applications.
Enhances process visibility and operational stability in industrial automation environments.
Provides stable signal conditioning for reliable long-term process monitoring.
Supports fast response performance for continuous industrial control operations.
Integrates with Honeywell Series 8 I/O architecture for simplified system configuration and maintenance.
Improves signal transmission reliability in power, chemical, manufacturing, and process industries.

FAQ

Q1: What is the main function of the 8C-PAIN01 module?
A1: The 8C-PAIN01 is used for acquiring and processing 4–20 mA analog input signals in Honeywell Series 8 control systems.

Q2: How many input channels does the 8C-PAIN01 support?
A2: The module supports 16 single-ended analog input channels.

Q3: Is the 8C-PAIN01 suitable for harsh industrial environments?
A3: Yes, the conformal-coated design provides protection against dust, moisture, and temperature extremes.

Q4: Which IOTA modules are compatible with 8C-PAIN01?
A4: It is compatible with 8C-TAIX51 non-redundant and 8C-TAIX61 redundant IOTA assemblies.

Q5: What industries commonly use the 8C-PAIN01 module?
A5: It is widely used in power generation, petrochemical, manufacturing, water treatment, and process automation industries.

Spares

I/O Module (Coated)	Description
8C-PAIH51	High-level AI HART
8C-PAIN01	High-level AI w/o HART
8C-TAIX51	AI IOTA, Coated
8C-TAIX61	AI IOTA, Redundant, Coated
8C-PAIM01	PMIO LL Mux
8C-TAIM01	PMIO LL Mux IOTA, Coated
MC-TAMT04	LL Mux TC FTA
MC-TAMR04	LL Mux RTD FTA
8C-PAOH51	Analog Output 16pt HART
8C-PAON01	Analog Output 16pt w/o HART
8C-TAOX51	AO IOTA, Coated
8C-TAOX61	AO IOTA Redundant, Coated
8C-PDIL51	Digital Input 24V
8C-TDIL51	DI 24V IOTA, Coated
8C-TDIL61	DI 24V IOTA Redundant, Coated
