Honeywell C7076A1015 adjustable sensitivity ultraviolet flame detector Original new

Honeywell C7076A1015 adjustable sensitivity ultraviolet flame detector Original new

Product Name:adjustable sensitivity ultraviolet flame detector

Brand Name:Honeywell

Model Number:C7076A1015

Country of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

honeywell c7076a1015 adjustable sensitivity ultraviolet flame detector original new-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Honeywell
CC-PAON01 51410070-175	C7076A1015
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	C7076A1015
Product Type	Adjustable Sensitivity UV Flame Detector
Operating Voltage	100 VAC, 50 Hz
Compatible Amplifier	R7886 Dynamic Self-Check UV Amplifier
Detection Type	Ultraviolet Flame Detection
Sensitivity Range	400:1 Adjustable
Ambient Temperature	-40°C to +71°C
Maximum Aspirator Temperature	107°C
Flame Signal Output	1.4 to 5.5 mA nominal
Housing Protection	NEMA 4
Wiring Connection	Terminal Block, Wire Clamp Type
Pressure Rating	20 psig (138 kPa) Maximum
Construction Material	Aluminum and Cadmium-Plated Steel
Dimension	12x26x10cm
Weight	3.08kg

Description

TheC7076A1015adjustable sensitivity ultraviolet flame detector is engineered for reliable flame supervision in industrial combustion systems. Designed for burner management and flame safeguard applications,C7076A1015delivers accurate ultraviolet flame sensing for gas, oil, and pulverized coal burners. Its solid-state design improves operational stability while supporting long-distance signal transmission in demanding process environments.

Integrated withR7886Dynamic Self-Check Ultraviolet Amplifiers, theC7076A1015provides continuous self-monitoring functionality to enhance combustion safety and minimize false flame signals. The detector features dual independent sensitivity adjustments with a wide dynamic range, allowing optimized flame discrimination across single-burner or multi-burner installations.

Compatible models includingC7076A1007andC7076A1031are widely used in power generation, petrochemical processing, steel production, and industrial boiler systems. With rugged construction, NEMA 4 protection, and dependable UV sensing performance, theC7076A1015is suitable for harsh industrial environments requiring stable flame detection and reliable burner control operation.

Applications

Power plants: Used for industrial boiler flame monitoring, burner management, and turbine combustion safety systems.
Oil & gas facilities: Supports reliable flame supervision in refinery furnaces and process heaters.
Chemical plants: Provides stable ultraviolet flame detection in hazardous process environments.
Steel mills: Suitable for high-temperature combustion systems and reheating furnace applications.
Cement plants: Monitors kiln burner flames and combustion control processes.
Industrial boilers: Ensures safe ignition and flame failure protection in multi-burner systems.
Machinery manufacturing plants: Applied in automated thermal processing and industrial heating equipment.

Features

Dual adjustable sensitivity controls for flexible flame discrimination
Solid-state circuitry for stable long-term operation
Compatible with dynamic self-check flame safeguard systems
High-level signal output for extended transmission distance
Supports multi-burner and multi-fuel combustion systems
Rugged NEMA 4 enclosure for harsh industrial environments
Field-replaceable electronic chassis design
Reliable UV sensing for gas, oil, and coal flames

Functions

Detects ultraviolet radiation emitted by industrial flames
Supports burner management and combustion safety control
Provides continuous flame verification for critical systems
Enables self-checking operation with R7886 amplifiers
Reduces false flame detection through sensitivity adjustment
Improves combustion reliability and operational safety
Supports flame discrimination in multi-burner applications

FAQ

Q1: What is the main function of the C7076A1015?
A1: The C7076A1015 is designed to detect ultraviolet radiation from industrial flames for burner safety and flame monitoring applications.

Q2: Which amplifier is compatible with the C7076A1015?
A2: The detector is commonly used with the R7886 Dynamic Self-Check Ultraviolet Amplifier.

Q3: Can the C7076A1015 be used in multi-burner systems?
A3: Yes, its adjustable sensitivity allows reliable flame discrimination in complex burner installations.

Q4: What types of fuel flames can this detector monitor?
A4: It can monitor gas, oil, and pulverized coal combustion flames.

Q5: Is the C7076A1015 suitable for harsh industrial environments?
A5: Yes, the detector features a durable NEMA 4 enclosure and stable solid-state electronics for industrial applications.

Spares

Number	Describe
191002B	Plug-in Electronics Chassis without ultraviolet sensing tube
190971E	Coil and Shutter Assembly for standard voltage models
190971F	Coil and Shutter Assembly for 100V models
191053	Ultraviolet Sensing Tube replacement component
191050	Quartz Viewing Lens for UV flame detection
117053	Meter Connector Plug for flame signal measurement
R7886	Dynamic Self-Check Ultraviolet Amplifier
C7076A1015	Adjustable Sensitivity Ultraviolet Flame Detector
C7076A1007	120V Adjustable Sensitivity UV Flame Detector
C7076A1031	220/240V Adjustable Sensitivity UV Flame Detector
ST50	Liquid-Tight Flexible Conduit Connector
STG-50	Neoprene O-ring and steel gasket assembly
32004766-003	High-temperature flame detector leadwire
Q7800	Wiring Subbase for flame safeguard systems
Appleton ST50	Watertight conduit fitting for NEMA 4 installation
