Product Name:Interface Module IM153-1 spare part SIMATIC DP
Brand Name:Siemens
Model Number:6ES7153-1AA03-0XB0
Country of Origin:Germany
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Siemens |
Model Number: |
6ES7153-1AA03-0XB0 |
Country of Origin: |
Germany |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Specification |
|---|---|
| Model | 6ES7153-1AA03-0XB0 |
| Product Type | IM 153-1 DP ST Interface Module |
| System | SIMATIC ET 200M |
| Protocol | PROFIBUS DP (EN 50170) |
| Transmission Rate | Up to 12 Mbit/s |
| Supply Voltage | 24 V DC (20.4–28.8 V) |
| Current Consumption | Max. 350 mA |
| Backplane Output | 5 V DC, max. 1 A |
| Power Loss | Approx. 3 W |
| Dimensions (W×H×D) | 40 × 125 × 117 mm |
| Weight | Approx. 360 g |
| Protection Class | IP20 |
| Isolation Voltage | 500 V |
| Operating Temp | 0 to 60 °C |
The 6ES7153-1AA03-0XB0 is a SIMATIC DP IM 153-1 interface module designed for ET 200M distributed I/O systems. It enables stable PROFIBUS DP communication and supports integration of up to 8 S7-300 I/O modules, ensuring flexible and scalable industrial automation architecture. As part of Siemens’ proven SIMATIC portfolio, including IM 153-1 DP ST variants, it delivers reliable field-level connectivity for complex process environments.
The 6ES7153-1AA03-0XB0 provides high-speed RS485-based data exchange with transmission rates up to 12 Mbit/s. Its robust design supports SYNC and FREEZE functions, as well as slave-to-slave communication for efficient real-time control.
Engineered for harsh industrial use, the 6ES7153-1AA03-0XB0 ensures electrical isolation, low power loss, and stable 24 V DC operation, making it ideal for continuous automation performance.
Q1: What is the 6ES7153-1AA03-0XB0 used for?
A1: It is used as a PROFIBUS DP interface module for ET 200M distributed I/O systems.
Q2: How many modules does it support?
A2: It supports up to 8 S7-300 I/O modules per DP interface.
Q3: What communication protocol does it use?
A3: It uses PROFIBUS DP based on RS485 transmission.
Q4: What is the maximum transmission speed?
A4: The module supports communication speeds up to 12 Mbit/s.
Q5: Is it suitable for industrial environments?
A5: Yes, it is designed for stable operation in harsh industrial automation systems.
