Product Name:3300 XL 8 mm Proximity Probes
Brand Name:Bently Nevada
Model Number:330103-00-08-05-02-CN
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330103-00-08-05-02-CN |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Specification |
|
Model |
330103-00-08-05-02-CN |
|
System Type |
3300 XL 8 mm Proximity Transducer |
|
Thread Type |
M10 x 1 metric thread |
|
Probe Diameter |
8 mm |
|
Total System Length |
0.5–9.0 m selectable |
|
Case Length Range |
20–250 mm |
|
Linear Range |
2 mm (approx. 0.25–2.3 mm usable) |
|
Operating Temperature |
-52°C to +177°C |
|
Cable Type |
75Ω triaxial FEP insulated |
|
Connector Type |
ClickLoc gold-plated connector |
|
Weight (Probe) |
~323 g/m |
|
Weight (System) |
~0.7 kg typical |
|
Dimension |
1.7x58x1.7cm |
The330103-00-08-05-02-CN3300 XL 8 mm proximity probe is engineered for high-precision vibration and position monitoring in industrial machinery. As part of the Bently Nevada 3300 XL series, it operates with a Proximitor sensor and extension cable to deliver stable, non-contact measurements based on eddy current technology, ensuring reliable shaft displacement detection in critical rotating equipment.
Built with an M10 x 1 threaded stainless steel housing, the330103-00-08-05-02-CNsupports flexible installation in tight mechanical spaces. It is designed for compatibility with both armored and non-armored configurations, offering enhanced durability in demanding environments such as turbines, compressors, and pumps.
With API 670 compliance and interchangeable system components, the330103-00-08-05-02-CNensures consistent performance, reduced calibration effort, and long-term stability in continuous condition monitoring systems.
Q1: What is the 330103-00-08-05-02-CN used for?
A1: It is used for non-contact vibration and position measurement in rotating machinery monitoring systems.
Q2: Is the 330103-00-08-05-02-CN compatible with other 3300 XL components?
A2: Yes, it is fully compatible with 3300 XL Proximitor sensors and extension cables.
Q3: What industries commonly use this probe?
A3: It is widely used in power generation, petrochemical plants, steel manufacturing, and machinery automation.
Q4: Does this probe support harsh environments?
A4: Yes, it is designed for high temperature, vibration, and electromagnetic interference conditions.
Q5: What thread type does this model use?
A5: It uses an M10 x 1 metric threaded design for secure industrial mounting.
| Number | Description |
|---|---|
| 04310310 | 3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread forming mounting screw; four screws required per sensor, standard for 3300 XL panel-mount housings |
| 03200006 | Silicone self-fusing tape, 9.1 m (10-yard) roll used for connector protection, electrical isolation, and environmental sealing (not recommended inside machine casing) |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables, includes connector protectors and installation tools |
| 136536-01 | Connector protector adapter enabling compatibility with pre-1998 installation tools for 75Ω ClickLoc connector systems |
| 40180-02 | Connector protectors package containing 10 pairs for 3300 XL 8 mm probes and extension cables, used for environmental protection |
| 03839410 | 75Ω triaxial male connector protector, designed for extension cable side to ensure secure environmental sealing of connector joints |
| 03839420 | 75Ω triaxial female connector protector for probe lead or extension cable connections, provides environmental and contamination protection |
| 04301007 | 3/8-24 probe lock nut with dual safety wire holes for secure mechanical fastening of probe installation |
| 04301008 | M10 x 1 probe lock nut with safety wire holes, used to secure probe mounting and prevent loosening under vibration conditions |
