Overview

Brand Name:	Bently Nevada
Model Number:	106M1081-01
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Specification Item	Details
Product Model	106M1081-01
Product Type	Universal AC Power Input Module
Compatible System	Bently Nevada 3500 Series
Input Voltage Range	85 to 264 Vac rms
Nominal Input Voltage	110 to 220 Vac
Input Frequency	47 to 63 Hz
Rack Configuration	Supports redundant power supply operation
Module Dimensions	2.5x12x12cm
Module Weight	0.32 kg
Operating Temperature	-30°C to +65°C
Storage Temperature	-40°C to +85°C
Humidity Rating	95% non-condensing
Compliance Standards	EMC, RoHS, ATEX, IECEx, cNRTLus
Installation Type	Half-height rack-mounted module

Description

106M1081-01 is a high-reliability universal AC power input module designed for the Bently Nevada 3500 Machinery Protection System. Working together with modules such as 106M1079-01, 114M5329-01, and 114M5330-01, it provides stable power conversion and dependable rack operation for industrial vibration monitoring and protection applications.

The 106M1081-01 supports a broad AC voltage input range and is engineered for continuous operation in demanding industrial environments. Its half-height modular structure allows easy installation within the left-side slots of the 3500 rack while supporting redundant power supply configurations for improved system availability.

Designed for power plants, petrochemical facilities, offshore platforms, and heavy manufacturing industries, the module delivers reliable electrical performance, strong EMC compliance, and compatibility with hazardous-area certifications. Its compact footprint, robust design, and maintenance-friendly architecture make it an ideal solution for modern machinery protection systems.

Applications

Power plants: Provides stable power input for turbine monitoring systems and machinery protection racks.
Substations: Supports continuous operation of industrial monitoring and protection equipment.
Chemical plants: Enables reliable power management in hazardous process automation environments.
Steel mills: Maintains dependable rack power under high-temperature and high-interference conditions.
Offshore platforms: Suitable for vibration monitoring systems in marine and offshore installations.
Machinery manufacturing plants: Used in automated production lines and rotating equipment monitoring systems.
Oil & gas facilities: Ensures uninterrupted operation of critical condition monitoring infrastructure.

Features

Wide universal AC input voltage support
Compatible with redundant power supply configurations
Compact half-height modular design
High EMC and industrial compliance capability
Suitable for hazardous-area applications
Stable power conversion for 3500 monitoring systems
Easy rack installation and maintenance
Reliable long-term industrial operation

Functions

Converts incoming AC voltage for 3500 rack modules
Supplies stable operating power to monitoring systems
Supports backup power redundancy operation
Protects rack systems from unstable power conditions
Enhances machinery protection system reliability
Maintains continuous rack operation during module replacement

FAQ

Q1:What is the function of the106M1081-01module?
A1:It serves as a universal AC power input module for the Bently Nevada 3500 monitoring system.

Q2:Can the106M1081-01support redundant power systems?
A2:Yes, it supports redundant rack power configurations together with a secondary power supply.

Q3:What input voltage range does the module support?
A3:The module supports 85 to 264 Vac rms input voltage.

Q4:Is the106M1081-01suitable for hazardous industrial environments?
A4:Yes, it carries ATEX, IECEx, and cNRTLus hazardous-area approvals.

Q5:Which systems are compatible with the106M1081-01?
A5:It is designed for use with the Bently Nevada 3500 Series Machinery Protection System.

Spares

Number	Describe
106M1079-01	Universal AC Power Supply Module
106M1081-01	Universal AC Power Input Module
129486-01	Legacy High Voltage DC Power Supply Module
129478-01	Legacy High Voltage DC Power Input Module
133292-01	Legacy Low Voltage DC Power Supply Module
133300-01	Legacy Low Voltage DC Power Input Module
114M5329-01	High Voltage DC Power Supply
115M7750-01	High Voltage DC PIM
114M5330-01	Low Voltage DC Power Supply
114M5335-01	Low Voltage DC PIM
01720025	Replacement Fuse for AC Power Input Module and Legacy High Voltage DC Power Input Module
01720045	Replacement Fuse for Low Voltage DC Power Input Module and Legacy Low Voltage DC Power Input Module
120M3877	Replacement Fuse, fast blow rated at 5A/500 Vac, size 6.3 x 32 mm for Universal AC Power Input Module
131150-01	Power Supply Blank Front Panel, quantity 1, includes screws
128085-01	Power Supply Rear Input Connector Cover, quantity 1
04310251	Screw for Power Supply Input Cover, quantity 2
129767	3500/15 Power Supply User Guide
118M0915-01	Replacement connector for Universal AC Power Input Module
118M0915-02	Replacement connector for DC Power Input Module
129M0198	Replacement fuse for High Voltage DC Power PIM (Power Input Module)
